1pcs S08k-sclcr06 8x125mm Turning Tool Boring Bar Holder For Ccmt0602

US $160

???, ???, China
Jun 9th

Open on mobile:
QR code

Specification: Product Name Internal Boring ToolHolder Model S08K-SCLCR06 Lead Angle 95 Degree Direction Right Hand Suitable Inserts CCMT 0602 (CCMT 21.51) Material Alloy Steel Color Black Shank Diameter 8mm (?5/16") Overall Length 125mm (5") Min.Bore 10mm (0.254") Package Content 1 x S08K-SCLCR06 1 x Suitable Wrench Product application Boring from light roughing to finishing in small bores Accepts Inserts CCMT0602 (CCMT21.51) Insert not included Product features Profiling bar for semi-finishing and finishing operations Bar hardness approximately 45HRC Extreme gloss finis Positive 80 degree diamond CCMT insert We also have high perfomance inserts on sell: Insert Grade: YBC251 Chip Breaker: HM Material: Carbide Coating: CVD Tin Al2O3 TICN Machining Parts Material: Steel Alloy Machining Process: semi-finish/medium Product application Material Group Material Type Examples ISO Code Cutting Application Steels & Alloy alloy steels, tool and die steels, ferritic/martensitic steels 1020, 1050, 4140, 4340, 8620, P20 P10 - P35 semi-finish/Medium Stainless Steel Ferritic/Martensitic, Austenitic, Austenitic/Ferritic (duplex) 301, 303, 304, 304L, 316L M20 - M35 semi-finish Steel Alloy Optimal (Min - Max) Cutting Speed Vc (SFM) 1049 (853 - 1312) Feed Rate (inch/rev) 0.009 (0.004 - 0.019) Depth of Cut (inch) 0.078 (0.019 - 0.118) Stainless Steel Cutting Speed Vc (SFM) 590 (393 - 853) Feed Rate (inch/rev) 0.009 (0.004 - 0.019) Depth of Cut (inch) 0.078 (0.019 - 0.118) Product features YBC251 Coating Grade Tin Al2O3 TiCN Carbide Substrate Surface with Tin coating to reduce friction and easily identify worn out spot Special structure Al2O3 layer forming a thermal barrier to protect insert from Anti-plastic deformation during high speed try cutting TiCN layer has high wear resistance characteristic Carbide substrate form by special crystal structure to increase the rigidness of the core base and thermal stability at high temperature YBC251 consist of tenacious carbide substrate with strong cutting edge and optimal layers of MT-TiCN, thick layer of Al2O3, Tin Coating. It's suitable for general purpose on wide range of material: finishing, semi-finishing and light roughing of steel, cast steel and stainless steel. Notice: 1. Due to the light and screen difference, the item's color may be slightly different from the pictures. Please understand. Make sure you don't mind before you bid.
