1pcs Soic8 Sop8 Flash Chip Ic Test Clips Socket Adpter Bios/24/25/93 Programmer

US $8.13

suzhou, China
Jul 17th

Open on mobile:
QR code

Product Description Product description: 1. When encountering a programmer with a protected function, the clip cannot be read under normal voltage. At this time, a 3.3V voltage needs to be added. The method is: The clip clamps the chip, the chip is pin 8 Apply a 3.3V voltage to the corresponding pin. Generally, there are two wires for the 3.3V power supply, then VCC corresponds to the clamp, and the other wire is directly grounded. 2. The non-disassembly clip belongs to the connector, which is oriented to the programmer. (There is no software, and no software is required. The software is only required for use with the programmer) The clip is only used for programming without disassembling the chip directly. On the application, you don’t need to solder it down) and there are no other high-end features. The principle is the same as putting the disassembled chip on the programming socket and inserting it on the programmer. The clip is purchased separately, and it cannot be operated without the programmer in hand. 3. The clip is suitable for wide-body SOP8 and narrow-body, with a wide range of expansion and contraction. Wide-body SOP8 models such as (W25Q series) and narrow-body SOP8 models such as (24C series) are generally understood to be 150MIL chips and 200MIL chips. Baidu checked on its own. Note: First of all, it is stated that the board does not need power supply for reading and writing chips. The first point: If you can read the bare chip by clamping it, but it cannot be read on the board, please check whether your contact is in good contact, and whether the metal of the clamp and the chip pins on the board are perfectly connected. The second point: your programmer and whether the chip is correct, the chip is flat on the table, the dot is the first pin, and the order is counted from the first pin to the left, 12345678, one pin of the chip must correspond to your programming The pins of the device should not be in disorder, and they cannot be read directly if they are plugged in reverse. The third point: Is there a driver for installing the programmer The fourth point: Whether there is a problem with the chip, the pin is aging, or the programmer does not support it, peripheral interference, etc. are all the problems. Please do not ask whether this clip supports the chip of a certain type. Please state that as long as it is a SOP8 chip, the clip can be clipped (except for TSSOP chips). Whether it supports reading and writing depends on whether the programmer supports it. It's not that the clip support is not supported. Package list: 1 * Burning folder Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.
