1pcs Vnh2sp30 Stepper Motor Driver Module 30a Monster Moto Shield Replace L298n

US $11.99

China, China
Feb 26th

Open on mobile:
QR code

Ebay Shops Payment Delivery Time Surport & Warranty Store Policy Visit store: tinxi-clothes-shop Welcome to Tinxi store Coustom Notice - Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Please check with the local customs office to determine what these additional costs will be prior to bidding/buying. - We are a company in CHINA. Delivery from China will cost approximately 20-30 working days. Please pay attention to the shipping and delivery time before you bid. Thank you. Search Product Details 1PCS VNH2SP30 Stepper Motor Driver Module 30A Monster Moto Shield Replace L298N Article-Nr.:5401475 Product Details: Stepper Motor Driver Module Condition: new This is essentially a ramped up version of our Ardumoto motor driver shield. For this monster shield we've replaced the L298 H-bridge with a pair of VNH2SP30 full-bridge motor drivers. We've also beefed up the support circuitry so this board is capable of driving a pair of high-current motors! The VIN and motor out are pitched for our 5mm screw terminals (not included), making it easy to connect larger gauge wires When using this board in extreme high-demand applications it may be necessary to improve thermal performance with a heat-sink or fan and to solder the wires directly to the board instead of using a screw terminal (in addition to the myriad other complications present in a high-current system) However, when using the board at currents up to 6A the chips will barely become noticeably warm Voltage max: 16V Maximum current rating: 30 A Practical Continuous Current: 14 A Current sensing available to Arduino analog pin MOSFET on-resistance: 19 m? (per leg) Maximum PWM frequency: 20 kHz Thermal Shutdown Undervoltage and Overvoltage shutdown Color is shown as pictures PLS NOTE that due to lighting effects, monitor's brightness/ contrass settings ect, there could be some slight differences in the color tone of the pictures and the actual item! Package Included: 1 x Stepper Motor Driver Module Powered By Tinxi On Feb-25-15 at 22:26:22 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	See Description
Brand	See Description
Model	See Description
