1x TOT136 TOT-136 Matching Transformers Low Frequencies (ТОТ-136) Permalloy, US $570 – Picture 0
1x TOT136 TOT-136 Matching Transformers Low Frequencies (ТОТ-136) Permalloy, US $570 – Picture 0

1x Tot136 Tot-136 Matching Transformers Low Frequencies (ТОТ-136) Permalloy

US $570

  • Bulgaria, Bulgaria
  • May 24th
Open on mobile:
QR code
K&M Electronics Other Items In Our Store Feedbacks About Us Contact Us Add To Favorites 1x TOT136 TOT-136 Matching Transformers Low Frequencies (ТОТ-136) Permalloy The first output of the transformer is marked with a red dot on the side and is located in the upper left corner. The numbering of the rest of the findings made in a clockwise direction from the installation. Size mm: - A - 18; - A1 - 24; - A2 - 42; - B - 36; - B1 - 31; - L - 48; - H - 36.5; - H - 33 Load Resistance, ohm: - Conclusions 5 - 6 - 4 - Conclusions 5 - 7 - 5.6 - Conclusions 5 - 8 - 8 DC resistance of the winding, Ohm: - Primary -10.2 x 2 - Secondary -0.3 Maximum allowable voltage at the primary winding of -19 x 2 The number of turns of primary winding - 280 x 2 Transformation ratio - 0.123                                                                                                                                                                                                                                                                             We accept payment through PayPal.     You can shop with confidence. We have fast and professional customer support. We offer combined shipping and have value insured deliveries from our carrier. The order will be processed within 12-36 hours after payment is received. We make deliveries by registered airmail with priority, tracking number and recommendation. The average delivery times are: Europe: 8 to 14 business days All other destinations: 12 to 22 business days.
