2.2kw 220v Water-cooled Spindle Motor Er20 24000rpm&inverter& 80mm Fixture Cnc

US $320.00

SHANGHAI, China
Jul 12th

Open on mobile:
QR code

1 x 2.2KW ER20 water-cooled spindle motor 220V 1 x 2.2KW VFD Inverter 2HP Huan Yang Brand 1 x 80mm cast aluminium bracket 2.2KW WATER-COOLED SPINDLE MOTOR ENGRAVING MILLING GRIND Specification: Material: Stainless Steel Size: 80x213mm(Middle bdy diameter:80mmxLength:213mm) Power: 2.2Kw Voltage: 220VAC Current: 8A Frequency: 0-400Hz Speed: 10-24000rpm Cooling: Water-cooling Accuracy: 0.003--0.005 Runout off: Less than 0.02mm Bearing Lubrication: Grease Collet size: ER20 Bearings: 3 bearings(C7005x2 + C7002x1),P4 class Net Weight: 5.1kg Power supply interface: Professional aviation Interface, Interface 1234 marked 123 respectively connected to the inverter output end of the (U, V, W), 4 ground wire this interface must be safe ground. Main application: Wood, Aluminum, Stone, metal, glass, PVC industry 2. 2.2kw Inverter VFD Product Feature: 1)PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability; 2)Easy PLC function can realize 16 legs of speed and inverter control function; 3)RS485 communication port, adopting standard international MODBUS main circuit control; 4)With extremely strong anti-jamming capability 5)Low output ratting torque0.5HZ-150%, low speed running ability; 6)Carrier adjustable by 16KHZ, completely soundless working environment; 7)Broad voltage working area, normal running in 304V-456V; 8)Auto voltage regulation (AVR) technique, for ensuring the inverter load capability; 9)Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes; 10)With perfect error protection and short circuit starting protection capability; Tech parameters: 1) Input Voltage: 220V(+/-15%) 2) Output Voltage: 220V(+/-15%) 3) Input Frequency: 48-63 Hz 4) Output Frequency: 0-400 Hz 5) Input Phase:1 or 3 - phase 6) Output Phase: 3 phase 7) Warranty: 1 year from the date you purchased Specification Series HY inverters Control Mode SPWM Input Power 220V class:220V(+/-15%) 5-Digits Display & Status Indicator Lamp Displaying frequency, current, revolution, voltage, counter, temperature, FOR or REV rotation, and fault, etc. Communication Control RS-485 Working Temperature -10~40 Celsius Degrees Humidity 0-95% Relative Humidity(without dew) Vibration Below 0.5G Frequency Control Range 0.1~2500.0Hz Accuracy Digital: 0.1%(-10~40 Celsius Degrees); Analog: 0.1% (15Celsius Degrees---45Celsius Degrees) Setting Resolution Digital: 0.1Hz; Analog: 0.1% of max. Operating frequency Output Resolution 0.1Hz Operator Setting Method Press directly keys to set. Analog Setting Method External Voltage 0-5V,0-10V,4-20mA,0-20mA. Other Functions Frequency lower limit, starting frequency, stopping frequency, three skip frequencies can be respectively set. General Control Ramp Control Selectable 4-speed steps ramp-up and -down time (0.1-6500s). V/F Curve Set V/F curve at will. Torque Control Torque increase settable by max. 10.0%. The starting torque can reach 150% at 1.0Hz. Multi-Inputs 6 multi-function input terminals for 8speed steps control, program operation, switching of 4-speed Ramp, UP/DOWN function, counter, external emergency stop and other functions. Multi-Outputs 5 multi-output for displaying of running, zero speed, counter, external abnormity, program operation and other information and warnings. Other Functions Auto Voltage Regulation(AVR), Decelerating Stop or Coasting Stop, DC Braking, Auto Reset and Restart, Frequency Track, PLC Program Control, Traverse Control, Drawing Control,Auto Energy Saving, Carrier Adjustable (Up to 20KHz), etc. Protection Functions Overload Protection Electronic relay protection motor drive Drive(for constant torque 150% per min. for the kinds of fan 120% per min.) Fuse Protection When the fuse breaks, the motor will stop. Over-voltage 220V class:DC Voltage >400V 380V class:DC Voltage >800V Under-voltage 220V class:DC Voltage <200V 380V class:DC Voltage <400V Restart After Instant Stop Restart with Frequency Track after Instant Stop Stall Protection Stall protection in ramp operation Output Short Circuit Electrical circuit protection Other Functions Fin over-heat protection, restriction of reverse running, direct start after power on, fault reset, parameter lock PID, one-drive-more, etc. 3. 80mm cast aluminium bracket Shipping Please open the package and check if there are some damages before sign, if there are some damages,please do not sign and contact us immediately. We ship to worldwide,but if your country’s custom is strict,please contact us before you bid to check detail and confirmed. Payment Import duties,taxes and charges are not included in the item price or shipping charges.These charges are the buyer responsibility. Payment must be made within 48hours of the auction end time. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides. Pls email us before you want to leave any negative feedback. Refund Any reason required for all refund. Item must be in it's original condition and no physical damage,buyer responsible for all shipping cost. When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos. Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again.Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Application	Milling
Runoff	less than 0.02mm
Fixture	80mm
Motor Size	80x213mm
MPN	Does Not Apply
Operating Speed	10-24000rpm
Brand	RATTM MOTOR
Spindle/Inverter	2.2KW
Cooling	Water cooled
Model	2.2KW inverter & water-cooled spindle
Collet	ER20
Bearing	3pcs(C7005x2+C7002x1)
Lubrication	Grease
Motor Voltage	220V
Frequency	400Hz
UPC	Does not apply
