2.4" Lcd Display Full Assembled Dso150 Digital Oscilloscope 1msa/s 15001k +probe

US $43.85

Shenzhen, China
Jul 8th

Open on mobile:
QR code

Features: *Has automatic, conventional and single trigger mode, convenient to capture the instantaneous waveform *Digital displays waveform parameters, such as frequency, cycle, pulse width, duty cycle, maximum, minimum, average, peak value and effective value *Can be triggered by a rise or drop edge *The trigger level position is adjustable and with instructions *Vertical displacement is adjustable and with instructions *Waveforms before observable triggers *Can freeze waveform display at any time *Test signal source with 1KHz /3.3V square wave *Save/tune out the waveform, the shutdown waveform does not disappear *100 brand new and high quality Specifications: *2.4-inch color TFT LCD with 320 x 240 resolution *Maximum Real Time Sampling Rate: 1Msps *Precision: 12Bit *Sampling Buffer Depth: 1024 bytes *Number of Channel: 1 *Analog Band Width: 0~200KHz *Vertical Sensitivity: 5mV/Div~20V/Div (progressive by 1-2-5) *Trigger Position: 1/2 of buffer size fixed *Sensitivity Error: < 5% *Input Impedance: 1M Omega *Power Supply: 9V DC *Supply Current: 120mA *Maximum Input Voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe) *Coupling Methods: DC/AC/GND *Horizontal Time Base Range: 10 s/Div~50s/Div (progressive by 1-2-5) Package include: 1 x New Assembled Digital Oscilloscope 1 x Probe 1 x 9V 1A power adapter Note: this Oscilloscope without battery in it,must connect with the power adapter. On Jul-08-21 at 11:59:09 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Maximum Bandwidth	200 KHz
Features	Handheld/ Portable
Model	DSO150
Maximum Real-Time Sampling Rate	1 MSa/s
Number of Channels	1
MPN	Does Not Apply
LCD	2.4-inch colo
Oscilloscope Type	Digital Storage Oscilloscope (DSO)
Vertical Sensitivity	5mV/Div~20V/Div (progressive by 1-2-5)
Sampling Buffer Depth	1024 bytes
Sensitivity Error	< 5%
Trigger Position	1/2 of buffer size fixed
Power Supply	9V DC
Input Impedance	1M Omega
Maximum Input Voltage	50Vpp (1:1 probe), 400Vpp (10:1 probe)
Supply Current	120mA
Horizontal Time Base Range	10 s/Div~50s/Div (progressive by 1-2-5)
Coupling Methods	DC/AC/GND
UPC	889251514937
Digital Oscilloscope Resolution	12-bit
