2.8" Tft Lcd, Nxp Arm Cortex-m3 Lpc1768, Ethernet , Usb, Rs232, 18 Io

US $269.95

Mississauga, Ontario, Canada
Jan 29th

Open on mobile:
QR code

The uT2.8EVAL is a compact size starter kit designed to cover a wide range of applications. An "off-the-shelf" industrial grade board assembly is well suited to be embedded into the end customer product, offering an array of features, including: 2.8" vibrant colors touch TFT screen (320x240 pixels, 262K colors) Resistive touch screen with Touch-Pressure measurement 100Mhz ARM Cortex-M3 processor 18 analogical and digital IO points 10/100 Fast Ethernet with Auto-MDIX Host and Client USB port RS232 serial port Nonvolatile configuration/data memory Very accurate Real-Time-Clock with backup Piezoelectric buzzer In System Programming (ISP) Serial Wire Debugging (SWD) Single 24V power supply Download: uT2.8 Starter Kit User Manual Technical data: Display: 2.8" TFT-LCD, 262K/64K colors Resolution: 320 x 240 pixels Backlight type/lifetime: LED/>10,000 h at +25°C Controller: ILI9341 Touch screen: Type: 4-wire resistive Controller: TSC2046E Processor: NXP LPC1768 - ARM Cortex-M3, 100Mhz, 512kB on-chip Flash, 64kB SRAM DC Inputs: Number of inputs: 9 Input voltage: 24VDC (max 30VDC) Input current : 5mA Isolation voltage: 1000V RMS field side to logic side; 500V RMS between groups Analog Inputs: Number of inputs: 2 Input range: 0 ... 5V / 0 ... 20mA Input impedance: 150 Kohm / 220 ohm Input filter: 2nd order active low pass filter, fc = 1Khz SAR ADC Resolution: 12-bit Transistor Outputs:Number of outputs: 6 Voltage range : 10 ... 35 VDC Maximum load: 350mA per point Response time: 0.1 ms at 24 VDC Analog outputs:Number of outputs: 1 Outputs range: 0 ... 20 mA Maximum load: 500 ohms Resolution: 10 bits Ethernet port:Type: 10/100 Fast Ethernet Standards: IEEE 802.3, 802.3u Features: Auto-MDIX support USB port: Mode: Host/Device Connector type: 5 pins mini-AB Serial port: ISP programming / general use RS232 UART port Debug port:SWD debug interface (LPC-Link2, J-link and ULink compatibility) Sound: Type: piezoelectric buzzer Sound pressure: 60dBA/10cm min. Real time clock: Temperature Compensated Crystal Oscillator (TCXO) with integrated capacitors Typical accuracy: +- 3ppm from -15°C to +60°C Super Capacitor: 0.33F Timekeeping operation: 6.5 days @ 25°C (super capacitor fully charged) Configuration and data memory:Type: EEPROM Size: 256Kb + 2kb Status LEDs:Front panel power, activity and warnings/alarms LEDs Power supply: Voltage range: 10 ... 30 VDC Inrush current: 1A max at 30VDC Power consumption: 2.5VA max. RoHS compliant: Yes Operating temperature: -20°C ... 50°C Storage temperature: -30°C ... 65°C Relative humidity: 5 - 85 % non-condensed Weight: 180 grams Warranties: The warranty given by Embdev Design is valid up to twelve (12) months after the Buyer has received the product. Warranties no to apply to products where defects are result of improper use, negligence, tampering, modification, improper installation or repairs made by the Buyer. All returned products must be properly packaged, including all original packing materials, manuals, and software (if applicable), and shipping freight pre-paid. COD returns are not accepted. Embdev Design accept no responsibility for goods damaged or lost in transit. Other links: uT2.8CPI Series

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	embDev
MPN	UT28EVAL
Model	uT2.8CPI
Country/Region of Manufacture	China
