2 Channel Usb/wireless Relay Module (xbee,bluetooth,wifi ) +cell Phone Control

US $170

Hefei, China
Mar 6th

Open on mobile:
QR code

Watch the product video here: http://www.youtube.com/watch?v=o82buWfITPI&feature=youtu.be Description: This USB/Wireless Relay Module allows computer control switching of external devices by using the USB port of your computer! Meanwhile, It has a wireless extension port, can work with XBEE or Bluetooth Bee or Wifly Module, which mean now you can control your device by zigbee or Bluetooth or WiFi ! The TOSR0x module can powered by USB bus or DC power and provides two volt free contact relay outputs with a current rating of up to 10 Amp each. Relay power rating If the relay is used at a voltage or current exceeding this specification, the life of the contacts may be significantly shortened. A full datasheet for the relays used on the TOSR0x is here: G5LA datasheet If you use DC Power ,the Input voltage should be DC5V. First Step - Install the Driver The TOSR0x module uses FT232RL USB to UART chip . Before using the TOSR0x you will need to download the FT232RL Driver. Connect the TOSR0x and windows will detect it and ask for the drivers. Point windows to the inf folder and it will install the driver. The TOSR0x will now appear as a com port. Commands The TOSR0x operates with an easy to use command set as described in the table below. TOSR0x Baud rate : 9600 Test program and example source code To get the TOSR0x up and running in the minimum amount of time we have put together an example program to demonstrate the functionality of the module. Documents: User Manual G5LA datasheet FT232RL Driver Test Program Realterm serial debug tool Controlling a TOSR0x USB Relay Module Using Python (Thanks James!) Linux Python module iPhone APP (WIFI) Android APP(WIFI) Android APP(Bluetooth) May you also need: RN-XV WiFly WiFi Module $58.99 http://www.ebay.com/itm/RN-XV-WiFly-WiFi-Module-/320971319152?pt=LH_DefaultDomain_0&hash=item4abb61a770 WiFiBee WiFi Module RN-XV-Made by Tinysine $35 , save $23.99 http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=321204278193&ssPageName=STRK:MESE:IT Bluetooth Bee Module XBee Pin Out Compatible http://www.ebay.com/itm/Bluetooth-Bee-Module-XBee-Pin-Out-Compatible-/320967478746?pt=LH_DefaultDomain_0&hash=item4abb270dda XBee 1mW Wire Antenna - Series 1 (802.15.4) http://www.ebay.com/itm/XBee-1mW-Wire-Antenna-Series-1-802-15-4-/221037149673?pt=LH_DefaultDomain_0&hash=item3376d73de9 4 Channel USB/Wireless Relay Module -TOSR04(Xbee, Bluetooth and WIFI Extension) http://www.ebay.com/itm/4-Channel-USB-Wireless-Relay-Module-TOSR04-Xbee-Bluetooth-and-WIFI-Extension-/320967383175?pt=LH_DefaultDomain_0&hash=item4abb259887 8 Channel USB/Wireless Relay Module (Xbee,Bluetooth,WIFI ) +cell phone control http://www.ebay.com/itm/8-Channel-USB-Wireless-Relay-Module-Xbee-Bluetooth-WIFI-cell-phone-control-/320981535833?pt=LH_DefaultDomain_0&hash=item4abbfd8c59 2 Channel USB/Wireless Relay Module (Xbee,Bluetooth,WIFI ) +cell phone control http://www.ebay.com/itm/2-Channel-USB-Wireless-Relay-Module-Xbee-Bluetooth-WIFI-cell-phone-control-/221123947740?pt=LH_DefaultDomain_0&hash=item337c03acdc Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TinySine
Power Supply	USB or DC5V
Model	TOSR02
Maximum load current	10A
MPN	G504FFA4A76419
Dimensions	46mmx89mmx16mm
Country of Manufacture	China
Type	Relays
