2 Conductor, Security & Commercial Audio Cable,belden 6500pe,1000 Ft, Plenum-cmp

US $970

Madison, Wisconsin, United States
Jun 13th

Open on mobile:
QR code

This listing is for a 1000 foot roll of wire (Belden 6500 PE). The following information is from the Belden technical data sheet on this item (http://www.btx.com/customer/bttein/specpages/BEl-6500PE_ds.pdf) General Description: Security & Commercial Audio Cable, Plenum-CMP, 2-22 AWG stranded tinned copper pairs with Flamarrest® insulation, Individually Beldfoil® shielded and Flamarrest® jacket with ripcord Usage (Overall) Suitable Applications: Intercom/PA Systems and Sound/Audio Systems Physical Characteristics (Overall) Conductor AWG: # Conductors AWG Stranding Conductor Material 2 22 7x30 TC - Tinned Copper Total Number of Conductors: 2 Insulation Insulation Material: Insulation Trade Name Insulation Material Wall Thickness (in.) Flamarrest® LS PVC - Low Smoke Polyvinyl Chloride 0.010 Outer Shield Outer Shield Material: Outer Shield Trade Name Type Outer Shield Material Coverage (%) Beldfoil® Tape Aluminum Foil-Polyester Tape w/Shorting Fold 100 Outer Shield Drain Wire AWG: AWG Stranding Drain Wire Conductor Material 24 7x32 TC - Tinned Copper Outer Jacket Outer Jacket Material: Outer Jacket Trade Name Outer Jacket Material Nom. Wall Thickness (in.) Flamarrest® LS PVC - Low Smoke Polyvinyl Chloride .015 Outer Jacket Ripcord: Yes Overall Cable Overall Cabling Lay Length & Direction: Length (in.) Twists (twist/ft) 2.5 4.8 Overall Cabling Color Code Chart: Number Color 1 Black 2 Red Overall Nominal Diameter: 0.130 in. Mechanical Characteristics (Overall) Operating Temperature Range: 0°C To +75°C UL Temperature Rating: 75°C Bulk Cable Weight: 11 lbs/1000 ft. Max. Recommended Pulling Tension: 24 lbs. Min. Bend Radius/Minor Axis: 1.300 in. Electrical Characteristics (Overall) Nom. Inductance: Inductance (µH/ft) 0.180 Nom. Capacitance Conductor to Conductor: Capacitance (pF/ft) 45.000 Nom. Capacitance Cond. to Other Conductor & Shield: Capacitance (pF/ft) 81.000 Nom. Conductor DC Resistance: DCR @ 20°C (Ohm/1000 ft) 16.4 Nominal Outer Shield DC Resistance: DCR @ 20°C (Ohm/1000 ft) 16.750 Max. Operating Voltage - UL: Voltage 300 V RMS Max. Recommended Current: Current 2.8 Amps per conductor @ 25°C Notes (Overall) Notes: The jacket and shield are bonded so both can be removed on automatic stripping equipment. Drain wire is inside foil shield. Save time & money with FREE Auctiva Image Hosting. Auctiva, The complete eBay Selling Solution.
