(2) Dixson Bew51a Series Bar Graph & Dvm Industrial Displays 200 Scale Tested

US $210

Finksburg, Maryland, United States
Feb 17th

Open on mobile:
QR code

(2) Dixson BEW51A Series Bar Graph & DVM Industrial Displays 200 Scale TESTED Here is pair of Dixson BEW51A series bar graph & DVM industrial displays. They have been thoroughly tested by our engineer and are guaranteed to be in fine working order and good cosmetic condition with a few scratches, as shown in the photos. These Meters are rated for Nuclear use. Better than Mil-Spec! Only the Display/DVMs shown are included in the photos. Nothing else. From our engineer: "These units run off a single +5 VDC @ 0.55 Amps power supply. The input circuit is configured for 0 to 5 VDC input. The meter and bar graph are both calibrated from 0 to 200. So a 2.50 VDC input signal would indicate 100 on the bar graph and the DVM. The DVM section of the display uses the industry standard ICL7135 4 1/2 digit digital voltmeter IC". "There is also LED's to indicate low and high threshold levels and a alarm indication. There are three multiturn potentiometers to adjust these set points. But the adjustments had an interaction and I did not have the time to document their correct adjustment steps". Here is the link for specs on the newer programmable model: www.ametekvis.com/download/Datasheet%20BW051P.pdf Technical details: The Dixson BEW-51 series combined bar graph / digital panel meters were designed for high accuracy industrial control including industrial, nuclear, military and aerospace applications. Designed to monitor 0 to 5 Volt signals with full differential input to help avoid external interference. The bar graph meter has 51 LED's which are controlled by one PCB independent from the digital display. And has two calibration controls. The bar graph section also has three LED's for fault conditions: One for LO level, one for HI level and the third for Fault condition. Each fault indicator also drives an open collector to ground transistor for remote monitoring. The threshold levels for the fault LED's look to be controlled by the digital control processor U1. The Digital displays are controlled by the industry standard ICL7135 4 1/2 digit DVM integrated circuit. The digital display section also has two calibration controls. In normal operation the ICL7135 input is feed from dual opamp U5 (OP14). Jumpers W3, W4, W5 control the decimal place location when jumped. The jumper W1 can be moved to W2 and the DVM IC will be feed by pin 15 on the edge connector. In this mode the DVM will read to 0.999 Volts with apx 7.70 volts input. All the units we have opened will support the addition of a fourth LED display in location DS58. The factory part is HP 5082-7653 which are available new and surplus. See attached data sheets link for information on most all active components used in the meter unit. Here is a link to the .Zip file of our technical data sheets in .PDF Format: http://www.ridgeequipment.com/images/DixsonMeters.zip See our ebay store for more great deals. Many loads, attenuators, cables, manuals and other equipment available. Ridge Equipment Ebay Store Click here to Add Ridge Equipment to your Favorite Stores! Be sure to sign up for our Ebay Newsletter under the 'Email Subscriptions' heading for special ebay-only offers. Questions / Contact We are available 8.30 am to 5.00 pm Eastern Time and respond quickly to all email questions. Shipping or Payment questions? -- email admin@ridgeequipment.com Technical questions? -- email techsupport@ridgeequipment.com Can't wait for an email? Call us at 410 871 2273 You can fax payment information to us at 410 871 1255 Our Mailing Address: Ridge Equipment Company, Inc 2002 Bethel Road Suite 105 Finksburg, MD 21048 Payment We accept American Express / Visa / Master Card / Discover Directly Or Pay me securely with any major credit card through PayPal! Shipping 95% of our packages ship within 1 day! Shipping is calculated based on buyer's location using eBay's built in shipping calculator. We will combine shipping for multiple items. The calculated price includes a packaging charge to help cover the cost of foam-in-place packaging. We use this system for maximum protection when shipping electronic equipment. These images copyright Sealed Air Corporation Overseas Bidders: Click here for our International Terms and Conditions Be aware that many of our packages are too heavy to ship with the USPS. These must be shipped via UPS International. Return Policy We always accept returns if the item is not as stated. Returns are handled as repair, replacement, or refund at our discretion. We work with our customers to bring any problems to an acceptable resolution. 100% customer satisfaction is our goal. Shipping 95% of our boxes are shipped within 1 day of receipt of payment. Full Shipping Info Questions? We respond promptly to all email. We are also available by phone from 8.30am to 5.00pm Eastern Time All Contact Info Payment We accept all major Credit Cards and Paypal Full Payment Info Returns Returns are accepted if the item is not as described. Return Policy Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
