2 Dwyer Mercoid Da-7031-153-5 Pressure Switches 2 - 60 Psi

US $79.99

Millstone Township, New Jersey, United States
Jul 20th

Open on mobile:
QR code

2 Dwyer Mercoid DA-7031-153-5 Pressure Switches 2 - 60 PSI Mercoid DA-7031-153-5 pressure switch, brass Bourdon tube, range 2-60 psig, 13.5 psig min. deadband. Wetted Materials: Brass, 403 SS, or 316 SS. Temperature Limit: 180°F (82°C). Pressure Limit: Maximum pressure of the operating range. Enclosure Rating: General purpose, weatherproof or explosion-proof. Repeatability: ±1% of full operating range, ±1.5% on DS-7300 models. Switch Type: SPST mercury switch, SPDT mercury switch, SPDT snap switch, or SPDT hermetically sealed snap switch. Other circuit types available. Electrical Rating: See Catalog page. Electrical Connections: Screw terminal. Conduit Connection: General purpose: 1/2" hole for conduit hub. Weatherproof: 1/2" conduit hub. Explosion-proof: 3/4" female NPT. Process Connection: General purpose and weatherproof: 1/4" male NPT; 1/2" male NPT on range 15S and 16S. Explosion-proof: 1/2" male NPT and 1/4" female NPT. Mounting Orientation: Vertical. Set Point Adjustment: Thumbscrew. Weight: General purpose: 4 lb (1.8 kg). Weatherproof: 6 lb (2.7 kg). Explosion-proof: 8 lb (3.5 kg). Deadband: See Catalog page. Agency Approvals: CE, UL, CSA, FM. (Mercury switch units are not CE approved). (Consult factory for which models have what approvals.)

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	Brand	Mercoid
MPN	DA-7031-153-5
Number of Phases	2
UPC	Does not apply
