(2) Nat’l Semi Lmx2312 1.2gig Frequency Synth Chips

US $16.00

Oxford, Pennsylvania, United States
Jun 9th

Open on mobile:
QR code

(2) Nat’l Semi LMX2312 1.2Gig Frequency Synth Chips -- 1.2 GHz PLLatinum Ultra Low Power Frequency Synthesizer 1 pair. Getting too old (hands shake too much) to work on UHF/u-waves with surface mounts. Left-overs from my satellite days. Great lot for ham radio and electronics experimenters. The LMX2312 is high performance Frequency Synthesizer. It uses a selectable, dual modulus 32/33 and 16/17 prescaler. The device, when combined with a high quality reference oscillator and a voltage controlled oscillator generates very stable, low noise local oscillator signals for up and down conversion in Wireless Communication devices. Serial data is transferred into LMX2312 via a three-wire Interface (Data, Enable, Clock) that can be directly interfaced with low voltage baseband processors. Supply voltage can range from 2.7V to 5.5V. The LMX2312 is manufactured using National's 0.5 ABiC V silicon BiCMOS process and is available in 20-pin CSP packages. Data and info available on the web at web. - datasheetdir.com/LMX2312U+Frequency-Synthesizer. Current retail about $20 each.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Nat'l Semiconductor
Country/Region of Manufacture	Taiwan
Model	LMX2312
