2 Vernitron Nonwire Wound Variable Resistor Potentiometer 8.5k Ohms Military New

US $38

Westerville, Ohio, United States
Jun 6th

Open on mobile:
QR code

FOR SALE ARE 2 BRAND NEW MILITARY SURPLUS NONWIRE ROUND VARIABLE RESISTORS 8.5K OHMS. SHAFT IS 3/4" AND TOTAL LENGTH OF RESISTOR IS 1 3/4". THE PART NUMBER IS 412197-12 AND THE NSN IS 5905001340424. SPECIFICATIONS ARE AS FOLLOWS: 5905-00-134-0424 Features MRC Parameter Characteristics AAPN Section Quantity 1 AAQL Body Style Cylindrical servo mounted AARG Reliability Indicator Not established AAVL Pilot Diameter 1.56200 inches maximum AAVM Pilot Length 0.06200 inches nominal ABHP Overall Length 1.727 inches maximum ABPA Undercut Diameter 1.750 inches maximum ABPC Undercut Width 0.07800 inches nominal ABPM Body Diameter 1.767 inches maximum ABWV Shaft Diameter 0.125 inches nominal ABXF Shaft Length 0.750 inches nominal ADAQ Body Length 0.977 inches maximum ADAV Overall Diameter 2.120 inches maximum AECZ Mounting LIP Diameter 1.76700 inches maximum AEDA Mounting LIP Depth 0.09300 inches nominal AEDX Shaft Style Round AEFD Actuator Type Single shaft AEFH Effective Electrical Rotation IN DEG Angular Rotation 165.0 minimum and 175.0 maximum APXH Terminal Location Upper adjacent side two rows AXGY Mounting Method Clamp ring CBBL Features Provided Nonmetallic shaft CQCC Electrical Resistance PER Section 8.5 kilohms single section CQCH TAP Location From CCW Terminal PER Section IN DEG OF Effective Electrical Rotation 180.0 single section CQCK Rotary Actuator Travel IN Angular DEG 360.0 nominal CQGN Ambient Temp IN DEG Celsius PER Section AT Zero Percent Rated Power 85.0 single section CRFJ Temp Coefficient OF Resistance PER Section IN PPM PER DEG Celsius -300.0/+300.0 single section CRGD Power Dissipation Rating PER Section IN Watts 4.0 free air single section CRJS Fixed TAP Quantity PER Section 1 single section CRKS TAP Location Tolerance PER Section -5.0/+5.0 ohms single section CRSS Resistance Tolerance PER Section IN Percent -5.0/+5.0 single section CRSX Actuator Travel Control Feature Continuous motion CSBW TAP Location From CCW Terminal PER Section IN Ohms 4250.0 single section CSDH Ambient Temp IN DEG Celsius PER Section AT Full Rated Power 20.0 single section CSDL Standard Taper Curve PER Section A single section TEST Test Data Document 80020-41297 drawing (this is the basic governing drawing, such as A contractor drawing, original equipment manufacturer drawing, etc.; excludes any specification, standard or other document that may be referenced in A basic governing drawing) TTQY Terminal Type AND Quantity 4 tab, solder lug IF YOU HAVE ANY QUESTIONS, PLEASE FEEL FREE TO CALL ME 1-614-580-0951. You will not be disappointed. My feedback speaks for itself. If you have any questions please email me and please check out the other items i have for sale. If you have problems with your order, PLEASE CONTACT ME BEFORE LEAVING FEEDBACK. Thanks,mark ATTENTION! - ATTENTION! - NOTICE! - NOTICE! BEFORE LEAVING FEEDBACK PLEASE PLEASE PLEASE CONTACT ME.I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE.IF YOU BOUGHT THE WRONG THING,IT IS BROKEN,IF SHIPPING TOOK TO LONG OR EVEN IF YOUR HAVING A BAD DAY.I WANT TO HELP!!I WANT TO KEEP MY FEEDBACK CLEAN .
