2 x MCX thru hole Plug PCB Mount with solder post, US $4.64 – Picture 0

2 x MCX thru hole Plug PCB Mount with solder post, US $4.64 – Picture 1

2 x MCX thru hole Plug PCB Mount with solder post, US $4.64 – Picture 2

2 X Mcx Thru Hole Plug Pcb Mount With Solder Post

US $4.64

Shenzhen, Guangdong, China
Mar 10th

Open on mobile:
QR code

rfsupplier-ebay Contact us Store Home Best Deals Wholesale Payment & Shipping Return Feedback & FAQ About Us Store categories RF Cable Assembly ufl Pigtail SMA Pigtail SMB Pigtail N Pigtail BNC Pigtail TNC Pigtail MMCX Pigtail MCX Pigtail MC-Card Pigtail CRC9 Pigtail TS9 Pigtail Fakra Pigtail UHF Pigtail F Pigtail FME Pigtail Other Pigtail RF Connector SMA Connector SMB Connector SMC Connector N Connector BNC Connector TNC Connector UHF Connector MCX Connector MMCX Connector Fakra Connector F Connector FME Connector 7/16 Connector XLR Connector Other Connector RF Adapter SMA Adapter SMB Adapter N Adapter BNC Adapter TNC Adapter UHF Adapter F Adpater FME Adapter Other Adapter RF Coaxial Cable 3G Antenna 15Dbi 3G Antenna 13DBi 3G Antenna 12Dbi 3G Antenna 11Dbi 3G Antenna 10Dbi 3G Antenna 9Dbi 3G Antenna 7Dbi 3G Antenna 5Dbi 3G Antenna 3.5Dbi 3G Antenna 3Dbi 3G Antenna 2Dbi 3G Antenna 3G- Other GPS Antenna WIFI Antenna Other Antenna Aluminum Box Solar Junction Box Solar Panel Connector Crimp tool POE Part Other 2 x MCX thru hole Plug PCB Mount with solder post MCX micro-miniature RF connectors are suitable for 50 ohm applications an provide repeatable performance from DC to 6GHz. The snap on coupling feature allows ease of assembly in dense packaging layouts. The design of the connector encompasses the need for size reduction, low weight, durability, and reliable performance, which are required in RF circuits of mobile and fixed communication system. MCX type connectors enable a 30% space reduction over similar SMB/SMC types. MCX connectors are designed to conform to CECC 22220 specifications. Typical applications for MCX connectors include GPS, wireless communications and automotive. Product Series: MCX Product Type: Thru Hole PCB Mount Body Plating: Gold-plated Connector Body Style: Straight Connector Material: Brass Contact Plating: Gold Gender: plug Impedance: 50 Ohm Technical Characteristics Temp. range...................... -65~ +165°C Impedance........................50I ohm / 75 ohm Frequency Range..................DC 0-6GHz (50ohm) / 0-1.5GHz (75ohm) Working Voltage..................250V (50 ohm)/ 170V (75 ohm) Withstand Voltage................750V (50 ohm)/ 250V (75 ohm) Contact resistance Center Contact...................

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	superbat
Body Plating	Gold-plated
MPN	M03-SPPT4-11BS01*2
Product type	Thru Hole PCB Mount
Country of Manufacture	China
