20 Hp Weg Explosion Proof Electric Motor 3530 Rpm 256t Ul Csa Div 1 C D F G

US $1,430.00

Redmond, Washington, United States
Jan 29th

Open on mobile:
QR code

Electric Motors : Explosion Proof : Three-Phase : Explosion Proof - NEMA Premium Choose the rate below: 20 HP - 60Hz - 460V 20 HP - 50Hz - 380V 20 HP - 50Hz - 400V 20 HP - 50Hz - 415V Characteristics Output: 20 HP Poles: 2 Frequency: 60 Hz Torque: 29.4 lb.ft Voltage: 208-230/460 V Frame: 256T RPM: 3530 Full Load Amps: 50.6-46.2/23.1 A Efficiency (100%): 91.7 Power factor (100%): 0.89 Insulation: F Noise: 75 dB(A) No load current: 13.8/6.90 A In Rush (Times): 6.2 Output HP Frame Full Load Amps In Rush (Times) Locked Rotor Torque Break Down Torque 20 HP 256T 50.6-46.2/23.1 A 6.2 200 % 250 % Efficiency (%) Power factor (%) Service Factor Inertia L.R. Time Weight 50 75 100 50 75 100 91.0 91.7 91.7 0.79 0.86 0.89 1.15 1.4499 sq.ft.lb 26 s 357 lb Electric Motors : Explosion Proof : Three-Phase : Explosion Proof - NEMA Premium Description WEG Explosion Proof motors are suitable for applications requiring UL or CSA certification for hazardous locations. Thermally protected with thermostats, all motors manufactured are submitted to hydrostatic as well as other routine testing at the factory to ensure compliance to the required specifications. WEG NEMA Premium Efficiency Explosion Proof motors are specifically designed to meet or exceed all EPAct requirements for energy efficiency. Applications Petroleum and gasoline Flour / feed mills Grain elevators Fans Pumps Blowers Material handling equipment Other applications requiring motors UL or CSA listed for hazardous locations. Standard Features Efficiency Certification number CC029A according to US Department of Energy Regulations Three-phase, 60Hz Voltage: 208-230/460, 460 or 575V Squirrel cage rotor / Aluminum die cast Totally Enclosed Fan Cooled - TEFC (IP54) Ball bearings are supplied as standard Cast iron frame Class 'F' insulation Temperature rise: Class 'B' (80?C) Service factor: 1.15 Inverter Duty as per CSA Standard (LR50962) NEMA dimensions NEMA ratings design 'B' Continuous Duty (S1) 104?F (40?C) ambient temperature Altitude: 3300 ft (1000 m) 1045 Carbon Steel Shaft for frames up to 365T 4140 steel shaft for motors 404T and above. (3600 RPM motors supplied with 1045) Class 'F' insulation for all frames Class 'H' impregnation resin F1 mount Stainless steel nameplate Paint: Synthetic Enamel alkyd resin base (exceeds ASTM B117 salt spray test) Color: RAL 5009 - Blue NPT threaded terminal box Non-sparking fan Thermostats Greasing fitting from 3647T up to 586/7 Optional Features Special Voltages and frequency Stainless steel shaft C and D flanges F2 mount NOTES Note: Motors are tested according to IEEE 112 std. – method ‘B’ or C390 CSA Design B torque rating on nameplate can be re-plated for design C for 15-200Hp 1800 and 1200 rpm Energy efficiency motors verified by UL in addition to the DOE. CSA and UL approved ALSO ENERGY VERIFIED CSA C390-93(+) CSA approved - File LR 50962 Division I, class I, groups C and D Division I, class II, groups F and G UL approved - File E 87848 Temperature code T4 Frame 143T up to 326T Division I, class I, groups C and D Division I, class II, grops F and G Frame 364T up to 586/7 Temperature code T3C Division I, class I, groups C and D Division I, class II, groups F and G* * For group G, Service Factor 1.0 l Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	WEG Electric
MPN	02036XT3E256T
Model	02036XT3E256T
