2004 Tc-s2a Brother Cnc Drill Tap Machine. 14 Atc, 10k Rpm,

US $6300

  • Warren, Michigan, United States
  • Jun 24th
 Offering for sale here is one (1), Used, 2004 TC-S2A Brother CNC Drill Tap Machine.   PLEASE NOTE: We do not accept PayPal.  Before hitting the buy-it-now button, please call 586-754-9200, ask for Ebay sales, so we can discuss payment options.  This sale is a final sale, "as is", with no right of return.  It runs great and our feedback speaks for itself.  You are welcome to come to our Warren, MI (Detroit suburb)warehouse and perform and under-power inspection of the machine. Loading onto a truck is free.   We can quote shipping rates to any of the lower 48 states.   Thanks for looking at our product! SPECIFICATION:  (subject to purchasers verification) Travel distance: · X axis: 18.8" · Y axis: 14" · Z axis: 10.6" · Distance from table top surface to spindle end face: 6" - 17" Table: · Work area: 23.6" x 11.8" · Max. load weight (uniform load): 330 Lbs Spindle: · Spindle speed: 10 - 10,000 RPM · Spindle speed when tapping: Max .6,000 RPM Feed rate: · Rapid traverse rate: 1,417 IPM · Cutting feed rate (XY): 39" - 393" · Cutting feed rate (Z): 39" - 787" ATC: · Tool shank type: MAS. BT30 · Pull stud type: MAS. P30T-2 · Tool storage capacity: 14 · Max. tool length: 7.8" · Max. tool weight: 6.6 Lbs Tool change: · Tool to Tool: 1.1 Seconds · Chip to Chip: 1.8 Seconds Motor: · Spindle motor (continuous for 30 minutes): 16 - 11 HP Equipped With: · Brother CNC-A00 Conversational Control 14 Position ATC turret
