BUYER MUST EMAIL PRIOR TO PURCHASE FOR ACCURATE FREIGHT & CRATE CHARGES FOM CNC Router for Aluminum Extrusion Model:Argo 40 RM Year: Not Available Cosmetic Condition: Excellent Rating: 3) Used/Tested Replacement Cost: Not Available Technical Specifications: 380/460V, 60CY, 3PH Hours on Meter: 596.5 Axes travel X axis – longitudinal travel mm 4390 Y axis – transversal travel mm 1100 Z axis – vertical travel mm 425 Electrosplindle rotation 0°/90°/180° Work capacity X axis Longitudinal travel mm 4.150 Y axis Transversal travel with electrospindle 90° - 540 mm 0-90° - 460 mm 90°-180° - 540 0°-180° - 460mm Z axis Vertical travel 90° - 300 mm 90°/180° - 250mm 0°/90° - 250mm 0°/180° - 250 mm Axes movement X axis Rapid traverse: m/1’ – 100mm Acceleration: m/s 2 - 2,5 Y axis Rapid traverse: m/1’ – 60mm Acceleration: m/s 2 - 3 mm Z axis Rapid traverse m/1’ – 30mm Acceleration m/s 2 – 2mm Machine precision Positioning precision ± 0,13 Repeatability precision ± 0,07 Electro-spindle Cone: ISO 30 DIN 69871 Power 4 Kw Max. torque 6,5 Nm Max. rotation speed 12.000 rpm Tool replacement time 8 sec. Number of tools possible 6 N° Maximum tool weight 6 Kg. Maximum tool length 124 mm Maximum tool diameter 220 mm Numeric control Type:VISION PLUS Specifications for Install Total installed power: 10 kW Air consumption - cone cleaning: 27 Nl/min Air consumption per cycle: 44,5 Nl Continuous air consumption - electrospindle cooling 200 Nl / min Connection voltage 380/460 V Connection frequency 50/60 Hz Working pressure 7 atm Dimensions 18.6 ‘ (5668mm) X 6.2’(1875mm) X 8.1’ (2460mm) Weight (2460 Kg) Spindle Head Constructed with a system of crossed tables in lightweight alloy to obtain a reduction in weight, high resistance to loads and accuracy in the mechanical work they perform, all at the same time. The solution used has considerable advantages in terms of machining precision and maintenance. Electro-spindle Designed by Fom Industries, this electro-spindle ensures important performances, both at low number of revolutions as well as at high speed, to satisfy the increasing needs in terms of flexibility. The 4kW electro-spindle is equipped with constant torque, rotation speed up to 12,000 rpm, adjustable, positioning 0° / 90° / 180° for machining the three profile sides, forced air cooling, ISO 30 Tools Lubrication With pure oil, by means of a sprayer with over-pressure device (minimal lubrication). Working Area Situated on the base and made up of: 4 pneumatic vices (expandable) for locking the profiles. They slide on flat guide-ways with manual locking. Manual movement/positioning with position indicated on the control unit monitor. Clamping jaws are positioned using a patented pushbutton system. Patented pivoting clamping system ensures optimum adhesion to the profile. 1 retractable sliding pneumatic stop. Omega 200 Control PC PENTIUM 4 comprising: Windows XP Professional SP2. FomCam. Vision Interface 4 software for managing blocks of manual control and service on line - assistance interface Note: The programs are to be installed on a P.C. and with the above characteristics. FOM CAM Graphic interface based on the Windows operating system for planning the machining operations and the pieces which automatically generates the CNC program that can be executed by the machining centre. Program features: Easy to learn and easy to use, highly flexible 3D simulation of parts, tools and machinings Display the piece position on the machine Double cell machines management Vises and fixtures management Machining library for accessories DXF Profile Library Vise position optimization Automatic bar-code recognition Integration with ProF2 (window software) Cutting line and machining center management 5 axis machining FomCam is the new easy-to-use CadCam solution for the 3D and 2D machining design on profiles. FomCam supports all FOM machining centers, the FOM 3, 4 and 5 axis machines and the cutting and machining lines. An intuitive software solution, FomCam was developed in close collaboration with expert machine tool users and manufacturers in the industrial and window manufacturing sectors. FomCam makes possible any kind of machining and ensures the quality of the NC code Machining optimizations To make the machining even faster, the software automatically minimizes the numbers of tool changes and spindle movements saving considerable time. All specifications are listed to the best of our knowledge, please email with any questions prior to purchase. IMPORTANT NOTE: ALL EQUIPMENT LISTED IN OUR EBAY STORE IS SUBJECT TO PRIOR SALE! Machine Ratings: 1) New Surplus: Equipment or parts are new. 2) Demo/Floor Model: Demonstration use only, like new. 3) Used/Tested: A complete test/cycle was performed and no issues were found. 4) Used/Pulled/Good: Pulled from a working unit, and because of proprietary design, the complete working unit was de-manufactured, and the parts sold. 5) Used/Untested: Items that we did not test or cannot test. This item was received by us as an individual part or integrated equipment that could not or was not tested. Payment: Please do not submit payment until you receive a final invoice with all applicable charges. Should you submit payment without shipping, handling charges, and applicable tax you will receive a separate invoice. Items will not be shipped until invoice is paid in full. Paypal is the preferred method of payment. Please email for alternate methods of payment should you wish to pick-up your item in person. Payment is expected within 5 business days from the date of sale. If payment is not received within 5 business days, the item will be re-listed and a non-paying bidder alert will be submitted to eBay. If you will not be able to submit payment within the 5 day period, please notify us immediately. We may be able to offer an extension. This arrangement is on a case by case basis. Shipping: Buyer is responsible for all shipping, crate, freight charges, and any applicable taxes. Items will be shipped within 10 business days from the date payment is received/cleared. A tracking number will be provided upon shipment of your item. Please ensure we have the correct and current information to avoid delays in shipping and prevent lost or misdirected items. Return Policy: All merchandise is sold in "as is/where is" condition. There is no warranty, unless otherwise specified within the listing. On-Site inspection available upon request. In the event we have misrepresented the item or you receive an item that is different from the listings description, we will resolve the situation as quickly as possible. Terms of Sale: All merchandise sold in "as is/where is" condition. There is no warranty, unless otherwise specified. All sales within California are subject to a 8.0% Sales tax. By purchasing this item you are bound to the terms and conditions set forth by eBay and within OC Liquidations. If you do not agree with the terms and conditions of sale, please do not purchase. All listed prices are firm unless otherwise agreed upon between seller and buyer. OC Liquidations reserves the right to change the price and specifications of all items without prior notice. Buyer is responsible for all shipping, crate, freight charges, and any applicable taxes. Paypal is the preferred method of payment. Please email for alternate methods of payment should you wish to pick-up your item in person. Payment is expected within 5 business days from the date of sale. All sales are final. No refunds or returns are accepted. Contact Us: We encourage buyers to ask all questions prior to purchase. We will do our best to answer any questions you may have and will try to respond within a reasonable period of time. Excellent customer service and satisfaction is our goal, you are our #1 priority! If you are planning on leaving anything less than a 5 star rating, please consider that by doing so, this will have a negative impact on our business. If there is a problem with your purchase, please email prior to leaving feedback so that we may have the opportunity to resolve the situation amicably. We are available between the hours of 9AM to 5PM, Monday through Friday, Pacific Standard Time.
