200mhz 2gs/s Oscilloscope 16-channel Logic Analyzer Multimeter 3in1 Usb Utd4202c

US $1,190.00

Shenzhen, China
Mar 5th

Open on mobile:
QR code

UTD4202C UTD4000 oscilloscopes offer user-friendliness, outstanding technical indicators and a host of advanced features. They are your perfect tools to complete testing tasks swiftly and efficiently. This manual is a user guide for 7 models of this digital storage oscilloscope series : Model Bandwidth Single Channel Dual Channel Equivalent Sampling Rate Sampling Rate Sampling Rate UTD4042C 40MHz 2GS/s 1GS/s UTD4062C 60MHz 2GS/s 1GS/s UTD4082C 80MHz 2GS/s 1GS/s UTD4102C 100MHz 2GS/s 1GS/s UTD4152C 150MHz 2GS/s 1GS/s 50GS/s UTD4202C 200MHz 2GS/s 1GS/s 50GS/s UTD4302C 300MHz 2GS/s 1GS/s 50GS/s UTD4000 oscilloscopes offer a user-friendly front panel with clear indications to allows access to all basic functions for easy operation. The scaling and position buttons for all channels are optimally arranged for direct view operation. As design is based on the controls of traditional instruments, users can use the new units without spending considerable time in learning and familiarizing with operation. For faster adjustment to ease testing, there is an [AUTO] key to instantly display the appropriate waveform and range position. The performance features listed below will explain why UTD4000 series can fully satisfy your testing and measurement requirements : 2GS/s real-time sampling rate (dual channel 1GS/s, single channel 2GS/s and 50GS/s equivalent sampling rate) (only UTD4152C/UTD4202C/UTD4302C) Dual time base function; unrivaled waveform detail observation and analysis capabilities through the USB storage device Automatic waveform and status configuration Storage of waveforms, setup and bit map; waveforms and setups reproduction Automatic measurement of 27 waveform parameters; parameters testing and customization Automatic cursor tracing measurement Unique wave recording and replay function Built-in FFT Multiple waveform mathematics functions (including add, subtract, multiply and divide) Edge, video, pulse width, slew rate and alternate trigger functions Visual system help messages 24k storage depth; 60M equivalent storage depth; 1024k recording length 16-channel logic analyzer; 3 1/2 digital multimeter Unique envelop sampling feature with direct visual display of carrier wave details after amplitude modulation Quick waveform acquisition and colour change function that visually describes the strength of waveform Scroll display in scan mode for continuous monitoring of signal variations HD colour LCD system at 320 x 240 pixel aspect ratio Unique XY mode that displays the waveform and Lissajous figure USB drive system software upgrade Supports plug-and-play USB storage devices and capable of communicating with a computer Specifications: Technical Indicators Acquisition Acquisition modes Real time Equivalent Acquisition rates 2GS/s 50GS/s (UTD4302C/UTD4202C/UTD4152C) Average When all channels have made N acquisitions simultaneously, N is selectable from 2, 4, 8, 16, 32, 64, 128 to 256. Input Input coupling DC, AC, GND Input impedance 1M?±1.5% in parallel with 24pF±3pF. Probe attenuation factor 1X, 10X, 100X, 1000X 400V (DC + AC Peak, 1 M? input impedance) Maximum input voltage (10:1 probe attenuation); 5V (Vrms, BNC). Time delay between channels (Typical) 150ps Horizontal Waveform interpolation Sin (x) / x Storage depth 24K (Max) Equivalent storage depth (dual time base) 60M Recording length 1024K 1ns/div-50s/div (300MHz); Scanning range (s/div) 2ns/div-50s/div (200MHz, 150MHz); 5ns/div-50s/div (100MHz, 80MHz, 60MHz, 40MHz); At 1-2-5 increment. Accuracy of sampling ±50ppm (any time interval >=1ms) rate and delay time Time interval Single :±(1 sampling time interval + 50ppm x reading + 0.6ns); (?T)measurement > 16 average values : ± (1 sampling time interval + accuracy (full bandwidth) 50ppm x reading + 0.4ns). Vertical Model UTD4302C UTD4202C UTD4152C UTD4102C UTD4082C UTD4062C UTD4042C A/D converter (A/D) 8-bit resolution, two channels sampling simultaneously Deflection factor V/div Range (V/div) 1mV/div~10V/div(UTD4102C/UTD4082C/UTD4062C/UTD4042C) (at input BNC) 2mV/div~5V/div(UTD4302C/UTD4202C/UTD4152C) Displacement range >= ± 10 div (UTD4102C/UTD4082C/UTD4062C/UTD4042C) >= ± 5 div (UTD4302C/UTD4202C/UTD4152C) Analog bandwidth 300MHz 200MHz 150MHz 100MHz 80MHz 60MHz 40MHz Single bandwidth 100MHz 100MHz 100MHz 100MHz 80MHz 60MHz 40MHz Selectable analog bandwidth limit (Typical) 20MHz Low frequency response (AC coupling -3dB)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	UTD4202C
Sample Rate	2GSa/s - 2.9GSa/s
MPN	UTD4202C
Number of Channels	2
Type	Digital
Country of Manufacture	China
Bandwidth	100MHz - 349MHz
Country/Region of Manufacture	China
Channels	2
