2015 Lcd 12864 Mega328 Transistor Tester Diode Triode Capacitance Lcr Esr Meter

US $18.25

shenzhen, China
Jun 9th

Open on mobile:
QR code

2015 LCD 12864 Mega328 Transistor Tester Diode Triode Capacitance LCR ESR Meter Description Features: 1, using the latest Mega328 version 2015 V1.12 software, features more than the M8 version. 2, using the 12864 big LCD , 3, using the 9v battery (not include) 4, Measuring input has a protection circuit, can reduce false-positive charged capacitor for the instrument damage. Measuring input protection circuit, can reduce false-positive charged capacitor for the instrument damage 5, Affect the precision of resistance related to use thin film resistor, one over one thousand the rest also USES one percent thin film resistor 6, size :72x75x20mm 7, working voltage: 9V Stable 8, working current: 20 ma Technical performance: 1, one-button operation, automatic shutdown. 2, shutdown current is only about 20nA. 3, using 8MH crystals. 4, can automatically detect NPN, PNP bipolar transistors, N-channel and P-channel MOS FET, JFET, diodes, dual diode, thyristor small power unidirectional and bidirectional thyristor. 5, Automatic identification pin arrangement of components. 6, current amplification factor and base measuring bipolar,transistor -. Emitter threshold voltage. 7, can be coupled through the base -. Emitter threshold voltage and high-current amplification factor identification Darlington transistors. 8, can detect bipolar transistors and MOS pipe protection diodes. 9, measuring MOS FET gate threshold voltage and gate capacitance. 10, can be measured simultaneously with two resistors and resistor symbol is displayed. Display with four decimal values on the right side. Resistance symbol is displayed on both sides of the pin number. So you can measure the potentiometer. If the potentiometer wiper not be transferred to a extreme position, it can distinguish between the middle and both ends of the pin. 11, resistance measurement resolution is 0.1 ohm, can measure to 50M ohms. 12, can be measured capacitance. Capacitor symbol is displayed on the right display values can be displayed with four decimal value. Can measure the capacitance of 30pF-100mF resolution 1pF. 13, 2uF more capacitors can measure the value of the equivalent series resistance ESR. The two values can be displayed with a decimal, resolution of 0.01 ohms. 14, may be displayed in the correct order of two diodes and a diode symbol, and gives the diode forward voltage. 15, LED is detected as a diode, its forward voltage higher. LED combo is identified as two diodes. 16, Reverse breakdown voltage is less than 4.5V Zener diode can be identified. 17, can measure a single diode reverse capacitance. If the connection base and collector of the bipolar transistor or the emitter of a pin, the reverse can also be measured or collector junction capacitance of the emitter junction. 18, Will be able to get connected just one way to measure the rectifier bridge. 19, Although the capacitance measurement limit is 30Pf, but you can be measured by the measured capacitance with a known volume of at least 30pF capacitor in parallel, and then obtain the desired result is subtracted from the measurement results will parallel capacitor. Package Contents: 1pcs x 12864 Mega328 Transistor Tester Diode Triode Capacitance LCR ESR Meter 1.Features 1.1 Operates with ATmega328 microcontrollers. 1.2 Displaying the results to a 128x64 graphic LCD-Display. 1.3 One key operation with automatic power shutdown. 1.4 Shutdown current is only about 20nA. 1.5 Automatic detection of NPN and PNP bipolar transistors, N- and P-Channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. 1.6 Automatic detection of pin layout of the detected part. 1.7 Measuring of current ampli?cation factor and Base-Emitter threshold voltage of bipolar transistors. 1.8 Darlington transistors can be identi?ed by the threshold voltage and high current ampli?cation factor. 1.9 Detection of the protection diode of bipolar transistors and MOSFETs. 1.10 Measuring of the Gate threshold voltage and Gate capacity value of MOSFETs. 1.11 Up to two Resistors are measured and shown with symbols and values with up to four decimal digits in the right dimension. All symbols are surrounded by the probe numbers of the Tester (1-3). So Potentiometer can also be measured. If the Potentiometer is adjusted to one of its ends, the Tester cannot di?er the middle pin and the end pin. 1.12 Resolution of resistor measurement is now up to 0.01?, values up to 50M? are detected. 1.13 One capacitor can be detected and measured. It is shown with symbol and value with up to four decimal digits in the right dimension. The value can be from 25pF to 100mF. The resolution can be up to 1pF . 1.14 For capacitors with a capacity value above 0.18µF the Equivalent Serial Resistance (ESR) is measured with a resolution of 0.01? and is shown with two signi?cant decimal digits. 1.15 For capacitors with a capacity value above 5000pF the voltage loss after a load pulse can be determined. The voltage loss give a hint for the quality factor of the capacitor. 1.16 Up to two diodes are shown with symbol or symbol in correct order. Additionally the ?ux voltages are shown. 1.17 LED is detected as diode, the ?ux voltage is much higher than normal. Two-in-one LEDs are also detected as two diodes. 1.18 Zener-Diodes can be detected, if reverse break down Voltage is below 4.5V. These are shown as two diodes, you can identify this part only by the voltages. The outer probe numbers, which surround the diode symbols, are identical in this case. You can identify the real Anode of the diode only by the one with break down (threshold) Voltage nearby 700mV! 1.19 If more than 3 diode type parts are detected, the number of founded diodes is shown additionally to the fail message. This can only happen, if Diodes are attached to all three probes and at least one is a Z-Diode. In this case you should only connect two probes and start measurement again, one after the other. 1.20 Measurement of the capacity value of a single diode in reverse direction. Bipolar Transistors can also be analysed, if you connect the Base and only one of Collector or Emitter. 1.21 Only one measurement is needed to ?nd out the connections of a bridge recti?er. 1.22 Capacitors with value below 25pF are usually not detectet, but can be measured together with a parallel diode or a parallel capacitor with at least 25pF. In this case you must subtract the capacity value of the parallel connected part. 1.23 For resistors below 2100? also the measurement of inductance will be done. The range will be from about 0.01mH to more than 20H, but the accuracy is not good. The measurement result is only shown with a single component connected. 1.24 Testing time is about two seconds, only capacity or inductance measurement can cause longer period. 1.25 Software can be con?gured to enable series of measurements before power will be shut down. 1.26 Selectable facility to calibrate the internal port resistance of port output and the zero o?set of capacity measurement with the selftest . A external capacitor with a value between 100nF and 20µF connected to pin 1 and pin 3 is necessary to compensate the o?set voltage of the analog comparator. This can reduce measurement errors of capacitors of up to 40µF. With the same capacitor a correction voltage to the internal reference voltage is found to adjust the gain for ADC measuring with the internal reference. 1.27 Display the Collector cuto? current ICE0 with currentless base (10µA units) and Collector residual current ICES with base hold to emitter level . This values are only shown, if they are not zero (especially for Germanium transistors). 1.28 Thyristors and Triacs can only be detected, if the test current is above the holding current. Some Thyristors and Triacs need as higher gate trigger current, than this Tester can deliver. The available testing current is only about 6mA! Attention: Allways be shure to discharge capacitors before connecting them to the Tester! The Tester may be damaged before you have switched it on. There is only a little protection at the ATmega ports. Extra causion is required if you try to test components mounted in a circuit. In either case the equipment should be disconnected from power source and you should be shure, that no residual voltage remains in the equipment. Payment 1.we only accept payment view paypal. It is fast, Easy and Safe. 2.All major credit cards are accepted through our secure payment processor PayPal 3.Payment must be received within 7 business days of auction closing. Shipping 1. If you intend to bid for more than 1 item, then we can ship them together. The total shipping fee will be the sum of individual shipping fees. There is no further discount. 2. We only ship to ebay registered address. So please be assure your address in ebay is Correct and Valid. 3. Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. 4. Delivery time depends on destination and other factors, it may takes up to 30 business days. 5. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: Country Shipping time USA 8-12 business days UK 12-20 business days Australia & Canada 12-20 business days Europe & Others 20-25 business days The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! We ship item promptly and please rate us 5 star on shipping time according to ebay rules. Feedback If you are considering giving a neutral or negative or a low DSR(4 star or below), do write to us and give us an opportunity to address your concerns first. We are always stand-by to help for any questions or concerns. Positive feedback is automatically left for you after you left to us positive feedback. Contact Us 1.If you’re in any way dissatisfied or any question with your purchase,please feel free to contact us via ebay messages.And will response within 48 hours.We will try our best to solve it for you.We are committed to ensuring that you are completely satisfied with every transaction. Your satisfactory is our goals 2.Please allow 1-2 business days for us to response. If you do not receive any reply from us,please check your email ensuring your mailbox has not reached full size. 3.Due to some ISP SPAM filter settings, you may not be able to receive our replies; if you have problems receiving our emails, you may need to use a different email account to contact us. 4.If you encounter any trouble. Please give us the opportunity to resolve any problem. We understand the concerns and frustrations you might have and will try our best to resolve the issues. 5.We care about our valued customers and will always try to help you. So if you have any problems, please contact us promptly. Return Description 1. 12-months Warranty for defective items (excluding items damaged and/or misused after receipt). Buy with confidence 2. Refund or replacement request is available only the requests within 2 week after parcel received & returning the item as the same condition as received. 3. Please contact us to request a return authorization. Your name, auction number, and reason for return should be included in the email. All items returned must contain all original packaging materials. 4. Please repack the item carefully. Items returned will be tested and a new replacement will be shipped to the buyer immediately when found defective. In the event that a suitable replacement is not available then a refund will be issued. Shipping, handling and insurance fees are non refundable. 5. Return shipping is to be paid by the Buyer.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	12864 LCR ESR Meter
Brand	Unbranded/Generic
Country/Region of Manufacture	China
MPN	Does Not Apply
UPC	Does not apply
