2015 New 12864 Lcd Gm328 Transistor Tester Rlc Esr Meter Capacitance Npn Pnp

US $22.89

HONG KONG, Hong Kong
Jun 9th

Open on mobile:
QR code

lithium battery Version GM328 transistor \ RLC \ ESR Tester Description: Product Details: 1.1 Operates with ATmega328 microcontrollers. 1.2 Displaying the results to a 128x64 graphic LCD-Display. 1.3 One key operation with automatic power shutdown. 1.4 Shutdown current is only about 20nA. 1.5 Automatic detection of NPN and PNP bipolar transistors, N- and P-Channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. 1.6 Automatic detection of pin layout of the detected part. 1.7 Measuring of current ampli?cation factor and Base-Emitter threshold voltage of bipolar transistors. 1.8 Darlington transistors can be identi?ed by the threshold voltage and high current ampli?cation factor. 1.9 Detection of the protection diode of bipolar transistors and MOSFETs. 1.10 Measuring of the Gate threshold voltage and Gate capacity value of MOSFETs. 1.11 Up to two Resistors are measured and shown with symbols and values with up to four decimal digits in the right dimension. All symbols are surrounded by the probe numbers of the Tester (1-3). So Potentiometer can also be measured. If the Potentiometer is adjusted to one of its ends, the Tester cannot di?er the middle pin and the end pin. 1.12 Resolution of resistor measurement is now up to 0.01?, values up to 50M? are detected. 1.13 One capacitor can be detected and measured. It is shown with symbol and value with up to four decimal digits in the right dimension. The value can be from 25pF to 100mF. The resolution can be up to 1pF . 1.14 For capacitors with a capacity value above 0.18µF the Equivalent Serial Resistance (ESR) is measured with a resolution of 0.01? and is shown with two signi?cant decimal digits. 1.15 For capacitors with a capacity value above 5000pF the voltage loss after a load pulse can be determined. The voltage loss give a hint for the quality factor of the capacitor. 1.16 Up to two diodes are shown with symbol or symbol in correct order. Additionally the ?ux voltages are shown. 1.17 LED is detected as diode, the ?ux voltage is much higher than normal. Two-in-one LEDs are also detected as two diodes. 1.18 Zener-Diodes can be detected, if reverse break down Voltage is below 4.5V. These are shown as two diodes, you can identify this part only by the voltages. The outer probe numbers, which surround the diode symbols, are identical in this case. You can identify the real Anode of the diode only by the one with break down (threshold) Voltage nearby 700mV! 1.19 If more than 3 diode type parts are detected, the number of founded diodes is shown additionally to the fail message. This can only happen, if Diodes are attached to all three probes and at least one is a Z-Diode. In this case you should only connect two probes and start measurement again, one after the other. 1.20 Measurement of the capacity value of a single diode in reverse direction. Bipolar Transistors can also be analysed, if you connect the Base and only one of Collector or Emitter. 1.21 Only one measurement is needed to ?nd out the connections of a bridge recti?er. 1.22 Capacitors with value below 25pF are usually not detectet, but can be measured together with a parallel diode or a parallel capacitor with at least 25pF. In this case you must subtract the capacity value of the parallel connected part. 1.23 For resistors below 2100? also the measurement of inductance will be done. The range will be from about 0.01mH to more than 20H, but the accuracy is not good. The measurement result is only shown with a single component connected. 1.24 Testing time is about two seconds, only capacity or inductance measurement can cause longer period. 1.25 Software can be con?gured to enable series of measurements before power will be shut down. 1.26 Selectable facility to calibrate the internal port resistance of port output and the zero o?set of capacity measurement with the selftest . A external capacitor with a value between 100nF and 20µF connected to pin 1 and pin 3 is necessary to compensate the o?set voltage of the analog comparator. This can reduce measurement errors of capacitors of up to 40µF. With the same capacitor a correction voltage to the internal reference voltage is found to adjust the gain for ADC measuring with the internal reference. 1.27 Display the Collector cuto? current ICE0 with currentless base (10µA units) and Collector residual current ICES with base hold to emitter level . This values are only shown, if they are not zero (especially for Germanium transistors). 1.28 Thyristors and Triacs can only be detected, if the test current is above the holding current. Some Thyristors and Triacs need as higher gate trigger current, than this Tester can deliver. The available testing current is only about 6mA! Attention: Allways be shure to discharge capacitors before connecting them to the Tester! The Tester may be damaged before you have switched it on. There is only a little protection at the ATmega ports. Extra causion is required if you try to test components mounted in a circuit. In either case the equipment should be disconnected from power source and you should be shure, that no residual voltage remains in the equipment. Package Contents 100% Brand New 1 xGM328 lithium battery Version transistor \ RLC \ ESR Tester Battery is NOT include. We can also wholesale if you need a large quantity of item please contact us :) Shipping : We only accept your Paypal Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 1 business day by Air Mail when your payment is clear. Country Delivery Time Working Days (not including holiday) 5-7 8-10 11-14 15-19 20-22 >25 Working Days + Saturday + Sunday 5-9 10-14 15-20 21-25 26-30 >35 United States Rate (item arrived) 9% 50% 21% 13% 7% Refund or Resend United Kingdom Rate (item arrived) 10% 62% 20% 3.5% 4.5% Refund or Resend Australia Rate (item arrived) 23% 50% 13% 8% 6% Refund or Resend France Rate (item arrived) 1.5% 20.5% 45% 23% 10% Refund or Resend Germany Rate (item arrived) 5.5% 25% 35% 19% 15.5% Refund or Resend Canada Rate (item arrived) 0.0% 44% 35% 18% 3% Refund or Resend Spain Rate (item arrived) 1.5% 25% 50% 14% 9.5% Refund or Resend Payment : We accept PayPal only. All major credit cards are accepted through secure payment processor PayPal. Payment must be received within 7 days of auction closing. If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from me and will combine them for your review. Feedback We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. Refund&Reship: If you are dissatisfied with our item or service, then please follow the good eBay practice to contact us by ebay message before leaving any feedback. We are committed to resolve all issues in a friendly and satisfactory manner. We always reply to ebay messages within 1-2 business days. If you do not get a response from us, then please check your ebay message. we only reply ebay message, no send email. Original and return shipping fee will not be refunded or reimbursed under all circumstances. You must agree and acknowledge this term if you bid for this item. Therefore, please do not complain about having to ship back at your own expense. Contact US:: If have any question, Please contact us by ebay message(no e-mail). Reply within 24hours. We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply to your emails as soon as possible, however, due to high volume of daily incoming emails and time zone difference, we may not be able to reply your emails immediately. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Jul-27-15 at 13:49:26 PDT, seller added the following information:
