20ea 74hc595n 8 Bit Shift Regester Ships From Usa

US $9.99

Baton Rouge, Louisiana, United States
Mar 9th

Open on mobile:
QR code

20ea 74hc595 8 bit shift regester The 74HC595 is a very handy IC used in many microcontroller projects. You clock in 8 bits of data (like, on/off settings for 8 LEDs) via two lines, and when you toggle a third line, it pops these settings out on 8 outputs on the IC. So you trade 3 valuable lines on your microcontroller for 8 outputs - a pretty good deal, eh? This is called "Shifting data out" of the microcontroller by "synchronous serial communication". This is the serial part of the deal, where each bit is "shifted in" one at a time then they all appear at once n parallel on the chips output. ?8-bit ?Logic Family : HC ?Logical Function : Shift Register ?Operating Supply Voltage (Typ) : 5V ?Output Type : 3-State ?Package Type : DIP ?Propagation Delay Time : 265ns ?Operating Temp Range : -40C to 125C ?Operating Supply Voltage (Min) : 2V ?Operating Supply Voltage (Max) : 6V Spec PDF Link ---> http://www.bkbelectronics.com/pdf%20files/74HC595.pdf Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

74hc595

8 bit Shift Register
