20mhz Dds Digital Signal Generator Module With Sweep Function On Cpld + Stm32

US $64.99

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

20MHz DDS Signal Generator ** TTL Output with Sweep Function ** Description This is a digital signal generator based on Direct Digital Synthesis (DDS) technology. It is designed on CPLD & STM32: easy to use, high signal stability. The signal output is TTL: signal can be adjusted in terms of amplitude and DC offset. It also integrated sweep function: able to set the sweep frequency range and scan time. Very suitable & handy for both laboratory technicians and enthusiasts. Items include: 1x DDS Signal Generator 1 x Power Adapter 1 x USB Cable 1 x BNC Cable specifically designed for this signal generator CD with installation shield in English language Online technical support Specifications 20MHz DDS Signal Generator with Sweep Function Frequency Details Wave Form Sine,Square,Saw-shape,Triangle Sine Wave 1 Hz~20 MHz Square Wave 1 Hz~2 MHz Saw-shape Wave 1 Hz~2MHz Triangle 1 Hz~2 MHz Step 1 Hz TTL Output Frequency Range 1 Hz~20 MHz Output Amplitude >3Vp-p Fan-out >20 TTL load Sweep Function Range Fs ~ Fe Duration 1 ~ 99 seconds Amplitude Frequency/Vp-p <1 MHz 2 MHz 5 MHz 10 MHz 20 MHz Sine 9.26v 8.48v 6.16v 2.64v 0.63v Square 9.36v 9.36v -- -- -- Triangle 9.12v 7.36v 5.08v -- -- TTL Square 3.34v 3.34v 3.34v 3.18v 2.32v Output AC Bias ±2.5V Square Wave Duty Ration 1%~99% Other Innovative Details Automatic memorize setting USB-PC Communication Dual Power Supply – USB / Adapter power supply Display Display LCD TTL Output: Range: 1Hz ~ 20MHz Amplitude: >3Vp-p Sweep output value: >20 TTL load Sweep Function: Range: Fs ~ Fe Time: 1 ~ 99 second(s) For output details, please refer to above chart. Package includes: 1x DDS Signal Generator 1 x Power Adapter 1 x USB Cable 1 x BNC Cable specifically designed for this signal generator CD with installation shield in English language Online technical support Please Refer to below for some examples: 20MHz Sine Wave 1MHz Square Wave 1MHz TTL 1MHz Triangle Wave Also Providing other Signal Generators: Pls Click Here for Other Options Please Visit Our Store for More Special Prices & Top Quality Items: Click Here Shipping Product will be shipped within 1 business day (weekends and public holidays are not recognized as business days) after full payment is received and cleared. All item(s) will be shipped via int'l register air mail or EMS, it normally takes 7-15 business days to arrive. Might be later arrival if the item be checked by customs; Delivery time is 5-12 days to USA, and 7-20days to worldwide. Return Policy We accept Return for Buyer's any reason, but item must be "Sealed and Un-used Original Condition." If you already opened or used item, return will be NOT accepted. Shipping is NOT refundable. We will send refund as soon as returned item arrived. If you received wrong item, please let us know to resolve problem. We will exchange to correct item. (In this case, We will pay return shipping.) Everything we sell is 100% guaranteed authentic. We authenticate every item on our site before it is listed. We stand behind the authenticity of our items with a money-back guarantee. We appreciate your trust! Payment Terms We only accept payment through Paypal. Contact US Any query is wellcomed. Please feel free to drop us a message. Messages are replied within 16hours.
