20mhz Dds Signal Generator With Sweep Function * With English Software

US $5400

default, Hong Kong
Jun 9th

Open on mobile:
QR code

20MHz DDS Signal Generator (Direct Digital Synthesis) TTL Output with Sweep Function Here for sell is a digital signal generator based on Direct Digital Synthesis (DDS) technology. It is designed on CPLD & STM32 core chip: easy to use, high signal stability. Its signal output is TTL: signal can be adjusted in terms of amplitude and DC offset. It also integrates sweep function: able to set the sweep frequency range and scan time. Very suitable & handy for both laboratory technicians and enthusiasts. Specification Chart: 20MHz DDS Signal Generator with Sweep Function Frequency Details Wave Form Sine,Square,Saw-shape,Triangle Sine Wave 1 Hz~20 MHz Square Wave 1 Hz~2 MHz Saw-shape Wave 1 Hz~2MHz Triangle 1 Hz~2 MHz Step 1 Hz TTL Output Frequency Range 1 Hz~20 MHz >3Vp-p >20 TTL load Output Amplitude Fan-out Sweep Function Range Fs ~ Fe Duration 1 ~ 99 seconds Amplitude Frequency/Vp-p <1 MHz 9.26v 9.36v 9.12v 3.34v 2 MHz 8.48v 9.36v 7.36v 3.34v 5 MHz 6.16v -- 5.08v 3.34v 10 MHz 2.64v -- -- 3.18v 20 MHz 0.63v -- -- 2.32v Sine Square Triangle TTL Square Output AC Bias ±2.5V Square Wave Duty Ration 1%~99% Other Innovative Details Automatic memorize setting USB-PC Communication Dual Power Supply – USB / Adapter power supply Display Display LCD Key Features: TTL Output: Range: 1Hz ~ 20MHz Amplitude: >3Vp-p Sweep output value: >20 TTL load Sweep Function: Range: Fs ~ Fe Time: 1 ~ 99 second(s) For output details, please refer to the above chart. Package includes: 1x DDS Signal Generator 1 x Power Adapter 1 x USB Cable 1 x BNC Cable specifically designed for this signal generator CD with software in English language Photos of the generator in use: 20MHz Sine Wave 1MHz Square Wave 1MHz TTL 1MHz Triangle Wave Please Visit My Store for more Great Findings and Quality Products Shipping Product will be shipped within 1 business day (weekends and public holidays are not recognized as business days) after full payment is received and cleared. All item(s) will be shipped via int'l registered air mail or EMS, it normally takes 7-15 business days to arrive. Might be later arrival if the item be checked by customs; Delivery time is 5-12 days to USA, and 7-20days to worldwide. Payment We accept payment through PayPal. Return policy We accept Return for Buyer's any reason, but item must be in "Sealed and Un-used Original Condition." If you already opened or used item, return will be NOT accepted. Shipping is NOT refundable. We will send refund as soon as returned item arrived. If you received wrong item, please let us know to resolve problem. We will exchange to correct item. (In this case, We will pay return shipping.) Everything we sell is 100% guaranteed authentic. We authenticate every item on our site before it is listed. We stand behind the authenticity of our items with a money-back guarantee. We appreciate your trust! Contact US Any query would be highly welcome. Please feel free to drop us a message. We'll reply in 24 hours. Thank You! Merci! Gracias! Danke! ???????!Obrigado! Grazie! ??????????! ?????!Grazie! ??!??!
