20w ±5v To ±24 Positive & Negative Dual Output Power Supply Boost Convert Dl

US $8.36

Shanghai, China
Aug 5th

Open on mobile:
QR code

Product Name: 20W +- 5-24V Positive & Negative Dual Output Power Supply Boost-Buck Converter Packing list: 1 PCS 20W DC DCStep-up/Step-down Converter Positive and negative voltage Dual voltage Module Description: Input voltage 3.6~30V,output ±3~±30V adjustable Maximum output power: 20W (For details, please see the description at the bottom or ask us for information.) Conversion efficiency :69-89% Quiescent current: 3-4mA 20W DC-DC Boost-Buck Converter working frequency 180KHZ. Operating ambient temperature : -40~+85 Degrees Celsius Size : 60 x 34 x 15mm High efficiency up to 89% Built in Frequency Compensation Built in Soft-Start Function Built in Thermal Shutdown Function Built in Current Limit Function Note: 1 In order to obtain a more stable voltage, it is recommended that the output is greater than 15MA 2 V- cannot be used alone, or no voltage output.But you can just use V+ 3 The startup current of the module is 2.5-3 times the operating current. 4 Increasing the 1UF-10UF MLCC capacitor reduces the startup current

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
MPN	Does not apply
Output Voltage Range	±5V±6V±9V±10V±12V±15V±24
Brand	Unbranded
Input Voltage Range	5 to 30V
GTIN	Does not apply
Conversion Direction	Step-Down,Step-Up
Manufacturer Part Number	Does Not Apply
Current Conversion	DC to DC
