21x Ti Tl494cn Switchmode Pulse Width Modulation Control Circuit

US $4.49

Stara Zagora, Stara Zagora, Bulgaria
Jan 29th

Open on mobile:
QR code

21x Texas Instruments TL494CN Switchmode Pulse Width Modulation Control Circuit DESCRIPTION OF TL494 Complete PWM Power-Control Circuitry Uncommitted Outputs for 200-mA Sink or Source Current Output Control Selects Single-Ended or Push-Pull Operation Internal Circuitry Prohibits Double Pulse at Either Output Variable Dead Time Provides Control Over Total Range Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance Circuit Architecture Allows Easy Synchronization The TL494 incorporates all the functions required in the construction of a pulse-width-modulation (PWM) control circuit on a single chip. Designed primarily for power-supply control, this device offers the flexibility to tailor the power-supply control circuitry to a specific application. The TL494 contains two error amplifiers, an on-chip adjustable oscillator, a dead-time control (DTC) comparator, a pulse-steering control flip-flop, a 5-V, 5%-precision regulator, and output-control circuits. The error amplifiers exhibit a common-mode voltage range from –0.3 V to VCC – 2 V. The dead-time control comparator has a fixed offset that provides approximately 5% dead time. The on-chip oscillator can be bypassed by terminating RT to the reference output and providing a sawtooth input to CT, or it can drive the common circuits in synchronous multiple-rail power supplies. The uncommitted output transistors provide either common-emitter or emitter-follower output capability. The TL494 provides for push-pull or single-ended output operation, which can be selected through the output-control function. The architecture of this device prohibits the possibility of either output being pulsed twice during push-pull operation. PAYMENT We accept PAYPAL only SHIPMENT The item will be shipped out within 24-72 hours after full payment have been received. We will ship out the item by registered regular airmail with tracking number All item(s) will be shipped by registered priority airmail. Typical delivery times are: EUROPE (All countries): 8...14 days ALL OTHER destinations (North and South America, Asia, Africa, etc.): 12...20 days

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Texas Instruments
Model	TL494CN
