220v Automatic Cnc Channel Letter Bending Machine All-in-one Aluminum Bender

US $8,300.20

Rowland Heights, California, United States
Aug 13th

Open on mobile:
QR code

Description US Stock-Ving Automatic CNC Channel Letter Bending Machine Three-in-one for Aluminum, SS, Iron US Stock, Door-to-Door Service! 3 Years Warranty! Showroom in CA, USA. Support Local Pickup! 24H Technical SupportFree Engineer Technical Traning! No extra fee cost , No customs handling Troubles !!! Remark: The computer is not included, please prepare it by yourself. Max Bending Angle:360 degree. Max Approach Speed (in/sec)6 Max Bending Speed (in/sec)120 Model MBM-HS-8150 Operation principle Automatic feeding, slotting and bending Available material Aluminum, stainless steel, galvanized iron Slot angle 45°-135°(just for aluminum) Bending radius 7mm Material width 150mm Material thickness Aluminum 0.3-1.2mm, stainless steel 1mm Power 1800W Voltage 220V Working Air pressure 0.6Mpa Advantage: New type of three-in-one CNC bending machine, there are two working systems and different bending axis, one for stainless steel and iron, another for aluminum. When we need to slot and bend different materials, Don’t need exchange the cutter .we just need to convert into another system. and it is convenient for us to change the bending axis, just three to two minutes. Therefore, this new machine can save time and improve efficiency. Features: 1 Cut angle from 45 to 135 and it can control depth precision, by using the CNC axis. the processing of various types of profile bending angle precision. 2 Intelligent control of the software, intelligent inspection to avoid collision in character bending process. 3 Telescopic bilaterally symmetrical bending mode of the unique, the greatest degree of bending process to avoid interference, and greatly improve the bending strength 4 Stainless steel gouging unique, single slotted mode profile milling groove ,according to different characteristics of arbitrary switching material, the operation is simple and convenient. 5 Can read muti-vector file like the format such as AI,DXF matching with the engraving file perfectly. 6 Use rotary type handwheel to adjust the feed depth ,the operation is simple and convenient 7 Intelligent imported square guide rail and a high precision ball screw can adjust the depth of grooves. 8 Special specification and equipment is available Product Details: Main Parts: 1)Two Cutters: One is for Stainless Steel and the other is for Aluminum. While working, these two are always on the machine together, just no need to change. When making Stainless Steel, just use the Stainless Steel cutter; when making aluminum, just use the aluminum one. 2)Two Benders: Just like the two cutters above, One is for Stainless Steel and the other is for Aluminum. The difference is these two benders are separate on the machine. When we make different materials, we need to change, just 2-3 minutes will be ok. 3) Software: Easy to study and operate. 1. Encoder control feeding length, Auto-Compensation on slipping. 2. Adjust cutting depth automatically by software. 3. The whole machine is adjusted by software, no any working part adjusted by hand anymore. 4. Easy to Adjust. With more functional software, one software setting could work on different materials. 5. Bender Device(Head) adopt Steel Structure: As the main structure of the machine, the bender device(Head) made by steel, more stable and stronger during bend-working. 6. As the core part of the motion card, we use high-class CPU. Its cost comes up to 2-3 times than other machine suppliers. 7. The software is more functional: compensation on the straight line, arc, inline, outline, start and end location more functional; Bender machine and router perfect match. 8. Easy to Adjust. With more functional software, one software setting could work on different material. 9. Can read AI, DXF, and PLT format. Perfect match CNC Router. TECHNICAL SPECIFICATIONS: Samples: If you choose the option with computer, computer pictures as follows Remark: The air pump and computer is not included, please prepare it by yourself.The air pump should be above 0.6Mpa and computer should be W7 32-bit with PCI slot. Package: Quality report: Customer Case: Exhibition Gallery: Wooden Box: There is total one wooden box. Machine Dimension (73" x 35" x 51") 1850mm*880mm*1300mm Machine Weight 400kg Package Wooden box Packing Size (65" x 33" x 63") 1650mm x 850mm x 1600mm; Gross Weight 420kg

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Bundle Listing	No
Available material	Aluminum, stainless steel, galvanized iron
Model	Automatic CNC Channel Letter Bender
Product Code	MBM-JH-8150-US
Country/Region of Manufacture	China
Slot angle	45°-135°(just for aluminum)
Operation principle	Automatic feeding, slotting and bending
MPN	6539002467000
Material thickness	Aluminum 0.3-1.2mm, stainless steel 1mm
Brand	QOMOLANGMA
UPC	6927052988190
