2304 Mhz Pll Brick Oscillator, 13 Dbm Output

US $420

  • San Marino, California, United States
  • Jan 29th
Open on mobile:
QR code
2304 MHz PLL brick oscillator by Harris Farinon, model SD-104830-M2, OPT 005.   Contains a microstrip oscillator at about 2304 MHz that is phase locked to the X21, X22, X23, or X24 harmonic of an internal ovenized crystal oscillator.  Here I am using a 104.72727 MHz crystal (not included in auction):  the X22 harmonic is 2304 MHz.   There is a 2.3 GHz internal isolator on the output.  The 2304 MHz output is 13 dBm.   A red LED lights when the brick loses phase lock.   Requires a well-regulated  -20.0 VDC supply.   The spectrum analyzer (at 1 MHz/div), cables, crystal, and coax attenuators are not included in auction.   This "brick" is in very nice clean condition, and it works fine.  Choose your T0-5 size SC-cut crystal to phase lock the microstrip oscillator to a frequency from  2.2 GHz to 2.3 GHz.  Ships to USA for $8.00 via USPS Priority mail in antistatic bag, packed well,  and boxed.   No shipping out of USA.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Harris Farinon
Model SD-104830-M2, OPT 005.
