24kw Soundproof Diesel Generator 8hours Fuel Tank

US $7,990.00

Guangzhou, China
Aug 13th

Open on mobile:
QR code

24kw Soundproof Diesel Generator 8hours fuel tank Diesel generator set Generator Model HR-24GF Rated Voltage (V) 400/230 Frequency 50Hz/60Hz Power factor 0.8 Type 3P 4W Prime Power (kW/kVA) 24/30 Rated current (A) 43.2 Packaged Size(mm) 1900 x740 x 1200 Gross weight (kg) 720 Diese Engine Data Engine Model ZH4100D diesel engines Manufacturer Weifang Cylinder No. 4L Cylin der arrangement In-line , Direct injecting combustion chamber Cycle Four stroke Aspiration Natural Compression ratio 17:01 Bore * Stroke 100 mm * 115mm Displacement 3.26 litres Direction of rotation Clockwise viewed from front Rated power(kw/kva) 30.1/37.63 Governor Type Mechanical Lub oil Capacity (L) 9 Rated Fuel Consumption (L/h) 6.8 Specifications of Main Parts 1500RPM 50HZ Oil Pump type Single grade gear type Displacement /Speed (L/min/r/min) 62/2800 Water Pump type Centrifugal type Speed (r/min) 2800 Fuel injection pump type Ain-line plunger type Governor model RSV full range type Various temperature and pressure range 1500RPM 50HZ Lub oil temperature 95 Outlet cooling water temperature 90 Lub oil pressure 0.3~0.5MPa 0.01MPa , when at idling speed Fyel injection pressure 20+1.0MPa Fuel Consumption 1500RPM 50HZ 100%( Prime Power) Load 218 g/Kw.h 75%(Prime Power) Load 207 g/Kw.h 50%(Prime Power) Load 220 g/Kw.h Alternator Data Brand Brushless / brush alternator Model HJI-24 Rated Power(kw/kva) 24/30 Connecting Type 3 Phase and 4 Wires, “Y” type connecting Number of Phase 3 Number of Bearing 1 Power Factor 0.8 Protection Grade IP23 Altitude 1000m Exciter Type Brushless, self-exciting Insulation Class, Temperature Rise H/H Telephone Influence Factor (TIF) 50 Voltage Regulation, Steady State ±1% THF 2% Alternator Efficiencies 88.20%

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	HR30kw
UPC	Does not apply
Phase	3-Phase
Brand	Weifeng
Power Source	Diesel
EAN	Does not apply
ISBN	Does not apply
