(25) Wago 222-412 Lever-nuts 2-port Cage Clamp Marrett

US $11.95

Janesville, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

Wago LEVER-NUTS™ Cage Clamp® Connectors M/N #: 222-412 Qty: 25 pcs. Specifications Wago Series: 222 Wago Product No: 222-412 Dimensions: 5/8 ” x 1/2 ” x 7/8 ” Connector Type: Cage Clamp® Connection No. of conductors: 2 Compatible Wiring: Cu/Cu only Solid: 28-12 AWG (0.8 mm2 - 4 mm2) Stranded: 28-12 AWG (0.8 mm2 – 4 mm2) Body Material: Polyamide Color/Colour: Gray, with Orange Levers Connector Retention Style: Spring Clip Contact Material: Steel Voltage: 600V, (1000V limited) Amperage: 20 max Max. Temperature: 221? F (105? C) Approvals: UL listed, CSA certified, CE certified, RoHS Compliant FAST – SAFE – EASY Connect Stranded or Solid wire at the same connection LEVER-NUTS™ are the first lever operated Cage Clamp® connectors that connect both stranded and solid copper wires. Now you can use the speed and dependability of Lever-wire technology in every application. LEVER-NUTS™ are UL listed and CSA certified for 600 volts. LEVER-NUTS™ are perfect for new construction and retrofit work. LEVER-NUTS™ work with 28-12 AWG solid and stranded wire, at the same junction, making main, branch and fixture hookup fast, easy and safe. No more hunting for the right size wire nut. LEVER-NUTS™ are completely reusable, regardless of the type of wire used. Fast, Easy Installation The new LEVER -NUTS™ Cage Clamp® connectors makes the job of wire connecting easier. No more twisting and taping required. Simply strip the wire ( 3/8 "); insert the conductor and you’re finished. The integrated test port allows for continuity testing without reinsertion. To remove the wire, just pull up on the port lever and extract wire. 100% reusable! Safe LEVER -NUTS™ hold each wire individually, eliminating loose connections. LEVER -NUTS™ are touch-proof and rated to 105° C. LEVER -NUTS™ are UL Listed/CSA certified for 600 volts (1000 volts for fixtures and signs) and current rated to the largest conductor used (20 amps). See The Safety The ergonomic advantages of WAGO Lever-Nuts are easily recognized and recommended to reduce injuries and discomfort from wrist strain, while saving time and money. Save Time LEVER -NUTS™ provide up to 50% time savings on installation. Secure connections reduce expensive trouble shooting and warranty work. These items are factory new, manufactured in Germany by the Wago Corporation. Once you use these connectors you’ll never go back to Marrettes or any other twist-on wire-nut connectors. Your item will be shipped with your security/privacy in mind and to protect the unit(s) from damage during shipment. G Lot #1313 See the other items I have on offer at my eBay store. http://stores.ebay.com/sunroofguy
