2a 30v Programmable Driver Board For Dc / Stepper Motor * Pwm Control * L298n *

US $590

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

*Programmable Driver Board* for DC / Stepper Motor for your Wild Wild Racing Robot Projects Description This is our newly developed PROGRAMMABLE DC / Stepper Motor controller. It can program on AT89S52 MCU to control DC or stepper motor. The board suits your needs in learning MCU, robot racing car competitions, as well as development projects and design projects. Product Parameters: Size: 88 * 67 * 35 mm Core Chip: AT89S52 Based on L298N Work under voltage range: input 5~35V (the voltage is subject to motor rated voltage) Can drive DC or stepper motors of voltage between 5~30V Max output current: 2A (peak current 3A) Output: Up to 25W Board Features: 1. Signal Indicator LED 2. Motor speed adjustable 3. Strong anti-interference performance 4. Retro-current protection 5. Can independently control two (2) x DC Motors 6. Can independently control one (1) x Stepper Motor 7. PWM speed control (can control speed by PWM Signal) 8. Can control motor go CW/CCW - reversible control 9. The board uses optocoupler isolation. 10. P3 ports are all lead out 11. LED (4 digit) display 12. 4 x keys for input (can manage control programming of AT89S52) We offer board schematic & programming samples for you as well. 1. Drive two DC step-down motor. Port A & B can be used for PWM control. If robot car only need go straight forward, we can connect IN1, IN2 / IN3, IN4 the 2 groups, to repsectively high and low leve. Then we use MCU 2 ports to send PWM signal to control portA, B to control go forward, turning, and increase/decrease speed. 2. Control 2-phase stepper motor. Connect IN1,IN2 / IN3, IN4 , the 2 groups to MCU port. Send output continuous pulse signal. Signal speed determines motor speed. Change sequence of pulse signal can control motor go CW or CCW / reversible control. Board Schematic: (Pls contact us if interested in the schematic) Package Includes: 1 x * Programmable Driver Board* for DC / Stepper Motor Please Visit Our Store for More Special Prices & Top Quality Items: Click Here Please Visit Our Store for More Special Prices & Top Quality Items: Click Here Shipping Product will be shipped within 1 business day (weekends and public holidays are not recognized as business days) after full payment is received and cleared. All item(s) will be shipped via int'l register air mail or EMS, it normally takes 7-15 business days to arrive. Might be later arrival if the item be checked by customs; Delivery time is 5-12 days to USA, and 7-20days to worldwide. Return Policy We accept Return for Buyer's any reason, but item must be "Sealed and Un-used Original Condition." If you already opened or used item, return will be NOT accepted. Shipping is NOT refundable. We will send refund as soon as returned item arrived. If you received wrong item, please let us know to resolve problem. We will exchange to correct item. (In this case, We will pay return shipping.) Everything we sell is 100% guaranteed authentic. We authenticate every item on our site before it is listed. We stand behind the authenticity of our items with a money-back guarantee. We appreciate your trust! Payment Terms We only accept payment through PayPal. Contact US Any query is welcomed. Please feel free to drop us a message. Messages are replied within 16hours.
