2ch 160msa/s Function Signal Arbitrary Waveform Generator 25mhz 3.5" Tft Lcd Usb

US $253.00

Shenzhen, China
Apr 30th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you order. ET3325 Note: English menu is available. Only supports AC 220V power supply, not for AC 110V. ET33 series two-channel function/arbitrary waveform generator is equipped with direct digital synthesis (DDS) technology which enables output signal to be stable and accurate. Instrument output channel sets CH1 channel output and CH2 channel output. CH1 channel is major output channel for output of all the following functions; CH2 channel is an auxiliary channel for output of basic waveform and arbitrary wave. Key Features: l 3.5-inch 480x320 TFT LCD with clear graphic interface l Chinese / English menu available l Press key for help and information l File management supporting USB flash disk and local storage l Two-channel output with the highest output frequency of 10MHz (ET3310), 25MHz (ET3325), 40MHz (ET3340) l Sampling rate: 160MSa/S, vertical resolution: 12 bit and storage depth: 16k l 5 basic waveforms and 32 arbitrary waveforms in-built l Pulse wave output set in edge time l Internal/external AM, FM and FSK modulation function l Output of linear/logarithmic frequency sweep and burst waveform l Frequency meter of high precision of 160MHz l With RS232 interface, USB Device, USB Host interface supporting USB flash disk storage l Multi-functional arbitrary waveform editing software equipped Frequency Characteristics ET3325 ET3340 Waveform types Sine, square, triangle, pulse, noise and arbitrary waves (including DC) Sine 1uHz - 25MHz 1uHz - 40MHz Square 1uHz - 5MHz 1uHz - 10MHz Triangle 1uHz - 500kHz 1uHz - 1MHz Noise (-3dB) 7MHz Bandwidth 7MHz Bandwidth Pulse 100uHz - 5MHz 100uHz - 10MHz Arbitrary wave 1uHz - 5MHz 1uHz - 10MHz Frequency Resolution 1uHz Frequency Accuracy ±5ppm Sine Wave Characteristics Harmonic distortion >1Vpp 0-1MHz: <-45dBc 1MHz-10MHz: <-40dBc 10MHz-20MHz: <-30dBc 20MHz-40MHz: <-25dBc 0-1MHz: <-45dBc 1MHz-40MHz: <-40dBc Total harmonic distortion <0.2% (20Hz-20kHz, 1Vpp) Square Wave Signal Characteristics Rise/fall <20ns Time Overshoot <5% Duty cycle =<100kHz: 1%-99%; =<5MHz: 20%-80%; =<10MHz: 40%-60% (0.1% resolution) Dissymmetry (50% duty cycle) 1% Period + 5ns Jitter 6ns +0.1% Period Ramp Wave Characteristics Linearity degree =<0.1% Peak output Symmetry 0.0-100.0% (resolution 0.1%) Pulse Wave Characteristics Pulse width Min 20ns;1ns resolution Edge transition time Min 20ns Overshoot <5% Jitter 6ns +0.1% Period Arbitrary Wave Characteristics Channel CH1 CH2 Sampling speed 160MSa/S 160MSa/S Waveform amplitude resolution 12bits 10bits Waveform length 16k 4k Minimum rise/fall time <20ns <20ns Jitter 6ns+30ppm 6ns+30ppm Storage quantity 10 waveforms 10 waveforms Output Characteristics Amplitude (50?) Range 1mVpp-10Vpp =<20MHz 1mVpp-5Vpp >20MHz 1mVpp-3Vpp =<20MHz Accuracy ±1% set value ±1mVpp(1kHz Sine, 0 offset, >10mVpp) Resolution 1mV or 3 bit Flatness (relative to 1K Sine, 1 Vpp) ±0.1dB, =<100kHz ±0.1dB, =<100kHz ±0.3dB, =<5MHz ±0.2dB, =<5MHz ±0.4dB, =<25MHz ±2dB, =<40MHz Offset (50?) Range ±5Vpk , ac + dc ±1.5Vpk , ac + dc Accuracy ±(1% set value +5mV+0.5% amplitude) Output impedance 50? Protection Short circuit protection, automatically disables the waveform output when overloading SYNC Output Level TTL compatibility Impedance 50? Rise/fall time <25ns; Maximum frequency 25MHz AM Modulation (CH1) Carrier wave Sine, square, ramp, pulse and arbitrary waveforms (excluding DC) Source Internal/external Modulation wave Sine, square, triangle and ramp Modulation frequency 2mHz-20kHz Modulation depth 0%-120% FM Modulation (CH1) Carrier wave Sine, square, ramp, pulse and arbitrary waveforms (excluding DC) Source Internal/external Modulation wave Sine, square, triangle and ramp Modulation frequency 2mHz-20kHz Frequency offset 0-Maximum carrier frequency FSK Modulation (CH1) Carrier wave Sine, square, ramp, pulse or arbitrary waveforms (excluding DC) Source Internal/external Modulation wave Square wave of 50% duty ratio Keying frequency 2mHz-1MHz Frequency Sweep (CH1) Carrier wave Sine, square, ramp, pulse and arbitrary waveforms (excluding DC) Types Linearity/Logarithm Start/Stop Frequency 1uHz-Maximum carrier frequency Sweep frequency time 1ms-500s Trigger source Manual operating, internal, external Burst characteristics (CH1) Carrier wave Sine, square, ramp, pulse, noise and arbitrary waveforms (excluding DC) Pulse count 1-65535 or infinite, gated Start/stop phase 0-360° Internal period 1us-500s Gating source External Trigger source Internal, external, manual operating Frequency Meter Frequency range 1Hz-160MHz Frequency resolution 6 bit/s Voltage range and sensitivity 100mVpp-5Vpp Input adjustment input impedance 1M? coupled modes AC Trigger Input Level TTL compatibility Slope Rise/Fall Pulse width >100ns Reaction time <500ns(burst) <10us(sweep frequency) Modulation Input Impedance 1M? Signal range ±5V ac + dc General: Power Supply Supply voltage 200-240V, 45-65Hz Power consumption < 40W Display Types 3.5-inch TFT LCD screen Resolution 480x320 Color 16M color Environment: Temperature range Operation: 10C - +40C Non-operation: -10C - +60C Cooling methods Natural cooling Humidity range Below +35C: =<90% relative humidity +35C - +40C: =<60% relative humidity Interface RS232,USB Host, USB Device Standard accessories: power cord (US, UK, Euro or AU plug is available), BNC probe x1pcs, CD. Optional accessories: BNC clip, RS232 cable, USB cable.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Ch
MPN	ET3325
Model	ET3325
Country/Region of Manufacture	China
