2d Scanning Head For Yag Laser Marking Machine Tsh8618d

US $1,222.00

Beijing, China
Jul 22nd

Open on mobile:
QR code

Description 2D Scanning Head for YAG Laser Marking Machine, TSH8618D Features: Compact and tight structure Dust-proof Interference-proof Easy to install Effective haer-sinking system Specification: Model TSH8618D Aperture size(mm) 12 Max.scan angle ±20° Active scan angle ±12.5° Max.laser power(w) ND:YAG@1064nm 150 Small step response time(1)(ms) 0.4 Tracking error(ms) 0.2 Marking speed(2)(m/s) 1.5 Positioning speed(2)(m/s) 7 Writing speed(3)(cps) good quality 400 high quality 260 Zero drift(uRad./°C) <20 Scale drift(ppm/°C) <75 Long-term drift over 8 hours(mrad) <0.8 linearity(4) 99.9% Repeatability(uRad) <8 Max.RMS current(A/axis) 3 Peak current(A) 20 Input signals XY2-100 or Analog±5V,±10V Input power ±24V VDC±10%,Max.RMS 3.5A/axis Operating temperature 25°C±10°C Weight(without lens) 2.9KG 1. Settling to 1% of full scale with Min.Y mirror which the scanner can carry.All angles are in mechanical degrees. All above specifications are applicable after 60 sec warm-up. 2. With F=160MM lens. 3. With F=160MM lens,mark 1mm height SHX font characters(including letters and digits). 4. Within±20 optical angle. Applications: Marking, cutting, marking-on-the-fly, science and research

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	for YAG Laser Marking Machine
MPN	TSH8618D
Type	2D Scanning Head
Brand	QOMOLANGMA
Product ID	24694
UPC	8011717144668
