2in1 Et826 Intelligent Digital Oscilloscope Multimeter Auto Range Ac/dc Current

US $74.56

Shenzhen, China
Jul 27th

Open on mobile:
QR code

Features: 1.Analog Bandwidth : ACV/DCV/ACA/DCA 20kHz , 200k high-speed A/D sampling. 2.HD Display Screen. 3.Digital multimeter with 41-segment analog bar display,200k high-speed A/D sampling,4000 counts auto-range(can be selected manually), one-button switch of graphical waveform display during measurement. 4.High reliability with panel calibration technology and memory calibration, sparing the need for adjustment with potentiometer. 5.Storing 100 sets of data and 10 waveforms independently. 6.Capable of holding waveform and data during measurement,easy to view and analyze. 7.Realizing one-button automatic waveform capture,operator-friendly to learn and operate. 8.Displaying historical data and real-time measurement on the same screen with unique record reading mode for easy comparison. 9.Effectively eliminating resistance, distributed capacitance or interference signals with relative value measurement (clearing). 10.Extending battery life with automatic shutdown function. 11.Featuring DC/AC voltage/current, resistance,capacitance/mF (large capacitance). 12.Frequency/duty cycle, diode/continuity test. 13.Frequency measurement with 5Hz ~ 5MHz automatic switching range and the maximum input of 380VAC. 14.10A AC and DC current measurement with protection against voltage error. 15.Capacitance double gear design 0.1nf-100uf gear position: convenient for small capacitors to measure quickly. 16.10mf gear position: high capacitance and high accuracy are guaranteed. Specifications: Material: ABS Display: LCD display, 128*64dot-matrix graphics, 4000 counts LCD size: 60 * 40mm / 2.4 * 1.6in Backlight: white Power: 3 * 1.5V AA battery (not included) Input resistance: 10M Auto sleep: yes (the meter automatically auto sleep in 15 minutes without any operation of button) Power consumption: about 40mA Storage capacity: DMM data: 100 groups, waveform record: 10 groups Operation environment: 0~+40; <75%RH Storage environment: -10~+60; <90%RH Item size: 160 * 83 * 32mm / 6.3 * 3.3 * 1.3in Package Included: 1*Multimeter Oscilloscope 1*Pair of Test Pens 1*Protective Bag 1*User Manual On Jul-27-21 at 10:06:16 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Features	Handheld/ Portable
MPN	Does Not Apply
Analog Bandwidth	ACV/DCV/ACA/DCA 20kHz , 200k high-speed A/D sampling.
Material	ABS
Display	LCD display, 128*64dot-matrix graphics, 4000 counts
LCD size	60 * 40mm / 2.4 * 1.6in
Backlight	white
Power	3 * 1.5V AA battery (not included)
Input resistance	10M
Power consumption	about 40mA
Storage capacity	DMM data: 100 groups, waveform record: 10 groups
Operation environment	0~+40; <75%RH
Storage environment	-10~+60; <90%RH
UPC	6973691251027
Brand	Unbranded
