2mhz Dds Function Signal Generator Module Sine/triangle/square Wave Ttl Sweep

US $6200

  • Shen Zhen, China
  • Jan 29th
Open on mobile:
QR code
  2MHz DDS Function Signal Generator Module Sine/Triangle/Square Wave TTL Output With Sweep Fuction     Introduction of the instrument   This is a complete 2M DDS signal source, the use of DC5V power supply that can output sine, square wave (1% -99% duty cycle can be adjusted), triangle wave, and sawtooth waveforms and other functions, the maximum output of up to 9Vpp, frequency from 0.0Hz-2MHz .a resolution of 0.1Hz, both with dual reverse TTL output, can produce digital adjustable duty cycle of IGBT for driving two TTL signals , with a 60MHz frequency counter, also has a resolution of 1mV of the ADC, measuring range 0V to 5V, so the DDS product combines many functions in one. Main technology data                                   Output waveforms             Sine wave, Square wave and Triangle wave                 Output amplitude                  >=9Vp-p (signal output, no load)(MAX)                                             About 0.1Vp-p (MIN)                 Output impedance               50?±10%(signal output)                  DC offset                        ±2.5V(no load)                 Display                          LCD1602        Frequency range                  0.01Hz ~ 2MHz       Resolution                       0.01Hz(2mHz)                      Frequency Stability                ±1x10-6                 Frequency accuracy              ±5x10-6 Sine wave distortion           =98%  (0.01Hz~10kHz) Rise and fall time of square wave
