2n6055 4 Pcs, Metal Case Darlington Power Transistors By Motorola

US $260

Rainier, Oregon, United States
Aug 14th

Open on mobile:
QR code

4 Pcs. 2N6055 METAL CASE MOTOTROLA POWER DARLINGTON FOR AUDIO AMP. DARLINGTON SILICON POWER TRANSISTORS by MOTOROLA . . . designed for general–purpose amplifier and low frequency switching applications. • High DC Current Gain — hFE = 3000 (Typ) @ IC = 4.0 Adc • Collector–Emitter Sustaining Voltage — @ 100 mA VCEO(sus) = 60 Vdc (Min) — 2N6055 VCEO(sus) = 80 Vdc (Min) — 2N6056 • Low Collector–Emitter Saturation Voltage — VCE(sat) = 2.0 Vdc (Max) @ IC = 4.0 Adc VCE(sat) = 3.0 Vdc (Max) @ IC = 8.0 Adc • Monolithic Construction with Built–In Base–Emitter Shunt Resistors 2N6055 Datasheet, Equivalent, Cross Reference Search Type Designator: 2N6055 Material of Transistor: Si Polarity: NPN Maximum Collector Power Dissipation (Pc): 100 W Maximum Collector-Base Voltage |Vcb|: 60 V Maximum Collector-Emitter Voltage |Vce|: 60 V Maximum Emitter-Base Voltage |Veb|: 5 V Maximum Collector Current |Ic max|: 8 A Max. Operating Junction Temperature (Tj): 200 °C Transition Frequency (ft): 4 MHz Collector Capacitance (Cc): 200 pF Forward Current Transfer Ratio (hFE), MIN: 750 Noise Figure, dB: - Package: TO3

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	Number of Elements per Chip	1
Maximum Operating Temperature	200 °C (392 °F)
Country/Region of Manufacture	America
Series	2N6055
Mounting Style	Through-Hole
Type	Darlington Transistor
Minimum DC Amplifier Gain	750
Transistor Category	Power Transistor
Maximum Operating Frequency	4 MHz
Brand	Motorola
Number of Pins	3
Package/Case	TO3
