2pcs Ds1302 Real Time Clock Electronic Module For Avr Arm Pic Smd M11

US $290

Shenzhen,Guangdong, China
Jun 9th

Open on mobile:

DS1302(without battery) is introduced trickle charge the clock chip, containing a real-time clock / calendar and 31 bytes of static RAM, via a simple serial interface to communicate with the microcontroller. Real-time clock / calendar circuit provides seconds, minutes, hours, days, weeks, months, years of information, the number of days per month and leap year automatically adjust the number of days. Clock can be done by the AM / PM or 12 decided to use 24 hour format. Between the DS1302 and the microcontroller can simply use the synchronous serial communication mode, used only three port lines: (1) RST Reset (2) I / O data lines (3) SCLK serial clock. Clock / RAM read / write data to a byte or up to 31 bytes of character set way communication. DS1302 low-power work to maintain the data and clock information when power is less than 1mW Real time clock with the year 2100 to calculate the seconds, minutes, hours, days, weeks, months, years, the ability, as well as the ability to leap year adjustment 1.31 8 temporary data storage RAM 2.Serial I / O port pin makes the least number of ways 3.Wide range of operating voltage 2.0 5.5V 4.Current 2.0V, less than 300nA 5.Read / write clock or RAM data transmission when there are two single-byte transmit and multi-byte character sets transfer mode 6.8-pin DIP package or optional 8-pin SOIC package assembly according to the surface 7.simple 3-wire interface 8.Vcc = 5V and TTL-compatible 9.Optional industrial temperature range -40 to +85 10.Dual power tube for the main power and backup power supply Parameters: 1.PCB a single panel, size: 42mm * 24mm * 12mm(max) Net weight:10g Package weight:20g Color:green (as the picture shows) 2 with 4 holes, about 3.1mm in diameter 3 genuine spare battery for the celestial sphere CR2032, Voltage 3V, current is 260mAh, non-rechargeable batteries. 4 Crystal 32.768KHz, matching capacitance 6pF, size 2 * 6mm 5.DS1302 made large 8-pin DIP chip, chip, IC Block below for easy replacement and plug the chip 6 module operating voltage compatible 3.3V/5V, 5V and 3.3V microcontrollers can be connected with 7 Operating temperature: 0°C --- 70 °C NOTE: Wiring (to provide the program, for example, can take any IO port, the port defined in the program can be modified): VCC -> +5 V/3.3V GND -> GND CLK -> P02 Welcome to Horizon_electronic Although we are new in Ebay,we specialized in international business for more than 8 years We are professional in international business. We work with Reliable international post service company.we can make sure you can get your items in time, We package every parcel very carefully.We promise you will get your items in good situation Mian business We selling items with high quality and best price . All items will be tested before shipped. we seek for long term .We mainly selling ICs, electronic component , electronic modules. PCB board etc, We also have customer to find other items that do not selling in our store .pls contact us if you need , we can always provide the best price. Payment & Return Policy · We accept Paypal . · If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. · We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money. Feedback We appreciate positive feedback . we always try our best to service every customer .so if you have ant question ,PLEASE DON’T HESITATE TO CONTACT US IMMEDIATEDLY, we are always here to offer help . Shipping Policy All items will be shipped within 1~2 business day after payment. by China post or Singapore post or HK post, order more than $25, we provide free tracking number, order less than $25, customer need to pay $2 if need tracking number , Parcel will marked as 'GIFT' Ship to address provided by ebay if no special notes from buyer . Delivery Time: Normally, It Takes About 10-30 Business Days to Arrival for most Countries. *5-14 days to USA. *10-25 days to Australia / Canada. *14-30 days to major cities in Europe . *4 - 8 weeks to Italy , Brazil ,Russia. However, it may delay due to industrial strike action, severe weather, custom reasons or peak seasons, such as Christmas/New Year Holidays. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
