2Pcs Dual H Bridge L298N PWM Stepper Motor Drive Controller Board Module Arduino, US $80 – Picture 0
2Pcs Dual H Bridge L298N PWM Stepper Motor Drive Controller Board Module Arduino, US $80 – Picture 0

2pcs Dual H Bridge L298n Pwm Stepper Motor Drive Controller Board Module Arduino

US $80

  • Fort Collins, Colorado, United States
  • Nov 10th
Open on mobile:
QR code
2 Pieces Dual H Bridge L298N DC Stepper Motor PWM Drive Controller Module This L298N-based driver module is a high voltage, high current dual full-bridge driver designed to accept standard TTL logic levels and drive inductive loads such as relays, solenoids, DC and stepping motors from 5V to 35V. It can easily control the DC motor speed and direction, and can also control 2-phase stepper motors. It can be used for other projects such as driving the brightness of certain lighting projects such as high powered LED arrays using Pulse Width Modulation (PWM) control.  Two enable inputs are provided to enable or disable the device independently of the input signals. The module includes an onboard 5V regulator. When enabled by the jumper, the 5V is provided as an output on the power connector, and can be used as a 5V DC supply for your other circuit components. (When enabled, the module input voltage must be at least 6V). When disabled, a separate 5V input provides in order to control the logic level circuitry of this module.   Controller Parameters: Driver chip: L298N dual H-bridge driver Drive Voltage: +5V to +35V (Input voltage must be at least 6V when internal 5V regulator is enabled) Drive peak current Io: 2A / Bridge Logic power supply range Vss : +4V to +5.5V DC (Not required when internal regulator is enabled. When enabled, the 5V is available as an output on the power conenctor  Control signal input voltage range: 4.5-5.5V high 0V low Maximum power consumption: 20W Storage temperature: -25 ~ +130 C Dimensions (approx): 43mm x 43mm x 27mm LxWxH (1.7" x 1.7" x 1.1") Weight: 26g Package Includes:2x Dual H Bridge L298N DC Stepper Motor PWM Drive Controller ModuleSpecifications and operation instructions Each module is individually tested and static bagged in our US facility prior to shipment.  Get it faster! Ships in 1 business day from our US facility for quick delivery.  BEST OFFERS are considered for multiple lot orders only. Expand your DIY and Arduino-compatible development with these other Arduino-compatible development boards, shields and modules from Envistia Mall.  We provide FREE USPS First Class Shipping with Tracking - Not Economy Shipping
