2pcs L298n Dual H Bridge Dc Stepper Motor Drive Controller Board Module New

US $75

shenzhen, China
Jan 29th

Open on mobile:
QR code

inkfrog terapeak Product Name: 2pcs L298N Dual H Bridge DC Stepper Motor Drive Controller Board Module New More Items In Our Store,Click Here! Basic Attributes Name Double H Bridge Motor Driver Module Working mode Drived by H bridge (double lines) Control chip L298N ? ST ? Logical voltage 5V Driving voltage 5V ? 35V Logical current 0mA-36mA Driving current 2A (MAX single bridge) Storage temperature ? -20 ???? +135 ?? Maximum power 25W weight 30g Periphery dimension 43*43*27mm Product features: 1.Using L298N made by ST company as the control chip,the module has such characteristics as strong driving ability,low calorific value and strong anti-interference ability. 2.This module can use built-in 78M05 for electric work via a driving power supply part.But to avoid the damage of the voltage stabilizing chip,please use an external 5V logic supply when using more than 12V driving voltage. 3.Using large capacity filter capacitor,this module can follow current to protect diodes,and improve the reliability Real figure? L298N is a kind of high voltage,high current motor driver chip produced by ST company.Having 15 pins as package, this chip has such features as high working voltage(maximum voltage up to 46V),large output current(instantaneous peak current up to 3A,continuous working current 2A) and 25W of rated power.Two built-in H birdge high voltage and large current full bridge drivers can be used to drive the DC motor and stepper motor,relay coil and so on.Using standard logic level signal control,it has two enable control ends.It permits or prohibites device having a logic power supply input without the impact of input signal,which enables the internal logic circuit part works at low voltage.The chip can connects to external detecting resistor to give the variations to the control circuit.Using L298N chip to drive the motor,this chip can drive a stepping motor or four phase stepping motor,and two DC motors as well. Port function? Circuit principle diagram ? This module is integrated with a built-in 5V power.When the drive voltage is 7V-35V, it can enable the onboard 5V logic power supply;afterthe power supply,don't input voltage in the interface+5V power supply,but you can lead the 5V for external use. when ENA enable IN1 IN2 control OUT1 OUT2 when ENB enable IN3 IN4 control OUT3 OUT4 Applied cases: 1 Driving stepper motor The connection of driving a common 4 line 2 phase electric motor is shown in below figure after enable ENA ENB Input the following driving timing from IN1-IN4?then the speed and direction of the stepper motor can be controlled 2 Driving DC motor Because the module is drived by double H bridge,it can drive two motors simultaneously. The connecting method is shown inbelow figure after enable ENA ENB You can imput the speed and direction of PWM signal drive motor 1 from IN1 IN2 You can imput the speed and direction of PWM signal drive motor 2 from IN1 IN2 The signal is shown in the figure Product size: Maybe you also need the following parts 1pcs Stepper Motor+ Driver Board ULN2003 5V 4-phase 5 line 1pcs ULN2003 Stepper Motor Driver Board for Arduino/AVR/AR?M 1pcs 5 Axis CNC Breakout Board For Stepper Driver Controller mach3 1pcs CNC Router Single 1 Axis Controller Stepper Motor Drivers TB6560 3A 1pcs Dual H Bridge DC Stepper Motor Drive Controller Board Module L298N for arduino $ 2.98 + free shipping $ 1.67 + free shipping $ 16.8 + free shipping $ 13.77 + free shipping $ 4.22 + free shipping STC(51)-MCU PIC-MCU AVR-MCU ATMEL-MCU STM32-MCU C8051F-MCU MSP430-MCU Crystal Oscillator IC Socket DIY PCB Universal Board Dupont Line Digital tube Buzzer Arduino UNO board PIC Programming unit AVR ATMEL Programming unit Connector Kit USB to TLL Modules Power Modules LCD Modules RS232 TO TLL Moudle For more quantity, please contact us 1) We accept PayPal payment ONLY. . inkFrog Analytics On Apr-29-14 at 22:49:47 PDT, seller added the following information:
