2x Mxa088 Infrared Sensor Digital Counter 6 Digit,999999,automatic Counter Obje

US $113.48

Bangkapi, BA, Thailand
Jun 9th

Open on mobile:
QR code

2x MXA088 INFRARED SENSOR DIGITAL COUNTER 6 DIGIT,999999,AUTOMATIC COUNTER OBJECT,HUMAN ANIMAL12VDC,CIRCUIT BOARD KIT ASSEMBLED KIT (2Pcs.) Detail: This item is only the board , there are no battery holder / AC adapter in the package. Technical information - Require Power supply : 12VDC - Using the infrared sensor for detecting with 6 meters distance for barrier. - Maximum velocity of object detecting : 0.5 second. [ Speed of counting 0.5 second per 1 x object ] - Maximum count from 999,999. - The value of the count will be remained. Even without the power supply. Counting will be recorded in the memory of board. - PCB size : 3.55" x 4.45" This circuit is a digital counter for objects or people which can be applied to count people entering into the room, counting the number of product, and etc. FEATURES - Power supply : 12 VDC. With maximum 90mA. - Can be connected directly up to 10" big display of MaxxTronic. - Using the infrared sensor for detecting. - Maximum detecting distance : 6 meters (when receiver and transmitter are vis-a- vis). - Maximum velocity : 0.5 second/time. - Maximum count : 999,999. - The counting value will remain after turn off the circuit. - Dimensions : 3.55" x 4.45" CONNECTING - IN point is used for connecting the external counting signal or other devices. - 6V BACKUP point is used to connect 6VDC battery to protect all recorded value when electric power failure. - Jumper JP3 is used for setting the new number counting. OPERATION OF SWITCH (NORMAL MODE) - Switch SW6 is used for counting up. - Switch SW5 is used for showing on-off the operation of infrared module. - Switch SW4 is used for showing the velocity detecting value which have been set. TESTING THE INFRARED SIGNAL 1.Disconnect the power supply. 2.Turn the LED infrared to module infrared. 3.Supply the power. If the infrared sensor is properly aligned, the display will show digit, and unit's decimal point will light ; on the other hand, if the infrared sensor is not properly aligned, the display will show "------". So, rearrange both sensor in proper align, and be assure that digit and unit's desimal point are light. 4.In normal mode, if there is any obstacle, unit's decimal point will disappear, conversely, if there is non-obstacle, unit's decimal point will light as usual. HOW TO PRESET INITIAL NUMBER BEFORE COUNTING 1.Remove jumper JP3. 2.Press SW1-SW6 to preset the initial number. 3.When setting is complete, jumping JP3. HOW TO SET DETECTING SIGNAL 1.Press and hold SW5, then display will show value which have been set. 2.If onboard infrared will be used, please punch number 1 by using SW1. If external signal will be used via IN input, please punch number 0 by using SW1. HOW TO SET THE COUNTER SENSITIVITY 1.To see the previous sensitivity value press and hold SW4. 2.To set the delay time (from 0 to 9) use SW1. NOTE: - Use high number for slow moving object. - Use low number for fast moving object. RESET THE COUNTING NUMBER 1.Press and hold SW2, display will indicate "------". 2.Press SW1, display will indicate "000000". Free Shipping Handling WORLDWIDE. The package will be shipped directly from Thailand via Economy/Standard Small package Airmail, and it will take about 11-23 Business Days (or about 2-5 Weeks) **Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. **Please check with your country’s customs office to determine what these additional costs will be prior to bidding / buying Return Policy 100% Satisfaction Guarantee: If you are not satisfied with the product you purchased for any reason, please contact us for a return instruction within 30 days Shipping Handling costs are not refundable. Return shipping cost will be paid by buyer. We accept ONLY PayPal for payment. Contact us Please contact us by eBay message only.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Future Kit
MPN	MXA088
Model	MXA088
Country/Region of Manufacture	Thailand
UPC	Does not apply
