3.1" Serial:uart/iic/i2c/spi 128x64 12864 Graphic Lcd Display Module In Canada

C $15.89

Waterloo, Canada
Mar 7th

Open on mobile:
QR code

This item is made and shipped from Canada, sorry can't be combined with other items Item Description Shipping Return/Warranty Payment About us FAQ Description If you need large quantity of this item, please contact us in advance Serial:UART/I2C/SPI 128x64 Pixels LCD Display Module, NO BACKLIGHT Did you: 1, Hate to write code to drive LCD? 2, Don't have enough I/O pins to connect with LCD? 3, Don't have enough memory in your MCU to store FONT data? 4, Have special characters to display? This unique adapter is your solution, it has: 3 communication mode + 7 preloaded Fonts + Graphic Engine +4 Upload-able Fonts, will save lots of memory space and I/O resource on your project, with the easy remember commands or Arduino lib, you can use the LCD in couple of minutes! Draw character/line/circle/rectangle just cost less than 10 bytes of memory! Download Programing Manual Download Arduino lib and demo code mbed Library (Thanks for Michael Shimniok to contribute code) Watch Arduino Demo Code Video on Youtube Convert image to data tool(MSB Horizontal option) if the total quantity you ordered >=10 pcs, we can preload your custom Start Screen and user font, please contact us in advance. How to Disconnect LCD from PCB? You must handle it very carefully, and follow the procedure bellow, otherwise, the flat cable end on screen side is very easy be danmaged! What benefit you if using these products in your electronic projects? Save lots of the I/O resources: these products only need 1 to 3 I/O pins from your controller that depends on the communication type you want. Save huge memory space to store font and start screen: in these product, there are 7 preloaded fonts ready for your application, and also have 16KB memory space for your user fonts, once you uploaded the start screen or user fonts, it will stored in products. Easy to use: the commands sending to products are easy to remember and understand. Using user fonts function, you can display any graphs or characters in any language These products already integrated graphic functions such as: draw line/rectangle/circle/image, send few bytes of instruction to products, it will do it for you, that also save your lots of code space You can display contents in 4 different directions: 0º, 90º, 180º, 270º(clockwise) on same screen, the product will map the coordinate accordingly. FEATURES: Power Supply: 2.5V to 7.5V Power consumption:15mA @ 5.0V Communication mode: UART/I2C/SPI, detect your setting automatically Receiving buffer: 256 bytes Work with all microcontroller and microprocessor Communication signal can work on 3.3V and 5.0V TTL Default setting: UART baud 9600bps, I2C 0x27 address UART baud (bps): 300, 1200, 2400, 4800, 9600, 14400, 19200, 28800, 38400, 57600, 115200 Pixels: 128x64 Screen size: 83x42mm Product size: (WxHxD):83x42x6.5mm (3.3X1.65x0.25") Simple command sets, easy to remember Graphic engine integrated 7 preloaded fonts, font’s data structure full compatible with U8Glib 4 uploadable user fonts, can display any characters and graph very simple Draw characters or graph in 4 direction Contrast control able by software Connect with your master circuit: Digole Serial Display List Model Matix Product Size(mm) View Size(mm) Display Technology Backlight Weight(g) Monochrome Display Module DS24064LCD-1 240x64 150x57x14 113x30 (4.6") B/W LCD NO 120 DS24064LCD-2 240x64 150x57x14 113x30 (4.6") B/W LCD Green 121 DS12864LCD-7 128x64 82x52x6 71x35.5 (3.1") B/W LCD NO 30 DS12864LCD-6 128x64 72x49x9 61x30.5 (2.7") B/W LCD Yellow-Green 23 DS12864LCD-4 128x64 46x40x6 42x21 (1.8") B/W STN-LCD White 9 DS12864OLED-3W 128x64 34x30x5 30x15 (1.3") OLED-White -- 5 DS12864OLED-3B 128x6 4 34x30x 5 30x15 (1.3") OLED-Blue - 5 DS12864OLED-2W 128x64 30x30x5 22x11 (0.96") OLED-White -- 4 DS12864OLED-2B 128x64 30x30x5 22x11 (0.96") OLED-Blue -- 4 DS12864LCD-UNA 128x64 Universal LCD Adapter for most KS0108, ST7920 and ST7565 LCD controller 3 Color Display Module DS9664COLED-20 96xRGBx64 31x29 20x13.3 (0.96") OLED-RGB 65K Color - 4.5 DS160128COLED-46 160xRGBx128 53x38x5 36x28.5 (1.8") OLED-RGB 262K Color -- 14 DS160128CLCD-46 160xRGBx128 53x38x6.3 36x28.5 (1.8") TFT LCD -RGB 262K Color Adjustable Backlight 22 DS220176CLCD-56 220xRGBx176 61x44x6.5 44x35(2.2") TFT LCD -RGB 262K Color Adjustable Backlight 29 DS320240CLCD-73 320xRGBx240 53x81x7.5 44.4x59.2 (2.8") TFT LCD -RGB 262K Color Adjustable Backlight 35 Shipping May need 1 to 6 weeks, see below for detail We will ship item out in 1 working days by Canada Post. We ship to your Paypal address only!!, please verify your Paypal address before sending payment, Estimate Delivery time, except public holiday in Canada and your country (If you can't wait the described time, please don't buy it from us): Ship to Estimated weeks Ship to Estimated weeks North America USA 1 to 3 Asia HK, Japan 2 to 4 Canada 1 to 2 Others 2 to 5 Europe Germany 2 to 3 Australia 2 to 4 UK 2 to 3 Other Country in the World 2 to 6 Others 2 to 4 Return to top Return/Warranty Policy Return with no reason: Item must be sent out in original condition within 7 days since item received, Buyer can return item to our Service Department in Canada by buyer's convenience, Buyer pay the return shipment fee, Same way money refund as you paid. Return/exchange if defective or wrong item buyer received: Buyer must contact with us using ebay message system within 4 days since item received, WE pay the return shipment fee, Replacement or money refund are available upon buyer request. Please contact us using ebay message system in advance before leaving feedback if there were any problem with your items. E-care service: Click here to report problems/return items and more Return to top Payment Payment is expected within 8 days, Ebay Unpaid Item Assistant will open unpaid item case automatically if no payment received in 8 days. We accept Paypal only Return to top About us We try our best to help buyers to pick out the QUALIFIED products from dazzling market with reasonable price, Our goal is to be one of the best seller on ebay, buyer's satisfaction is our #1 concern Return to top FAQ Q: What can you do if my address is not correct? A: Buyer should take all responsibility for offering incorrect information. Return to top
