3.2"inch Tft Lcd Display Module + Touch Panel & Sd Card Cage For Arduino

US $13.50

default, default, Hong Kong
Jan 29th

Open on mobile:
QR code

3.2"inch TFT LCD Display module + touch panel & SD card cage for Arduino Item Description The 3.2” inch TFT LCD module integrated a SSD1289 TFT LCD controller and ADS7843 compatible touch screen controller as well as a SD card cage. It is suitable for embedded systems which require display high quality colorful image or video with interactive control and storage purpose. The Module interfaces to microcontrollers via a 2*20 Pin 2.54mm dual row pin header interface , can easily be connected to any microcontroller or FPGA and DSPs. Features: LCD Module is with SSD1289 Controller ADS7843 compatible touch panel controller Standard SD card cage Support 16 bit RGB565 format , can connect any 16 bit data bus Onboard 3.3V regulator require a single 5V supply 3.3V I/O voltage level tolerance Module Size (L * W * H): 94 * 64 * 14mm including connector Pin Definition: 1 GND 21 LCD_DB0 2 VCC 22 LCD_DB1 3 N.C. 23 LCD_DB2 4 LCD_RS 24 LCD_DB3 5 LCD_WR 25 LCD_DB4 6 LCD_RD 26 LCD_DB5 7 LCD_DB8 27 LCD_DB6 8 LCD_DB9 28 LCD_DB7 9 LCD_DB10 29 TouchP_CLK 10 LCD_DB11 30 TouchP _CS 11 LCD_DB12 31 TouchP _DIN 12 LCD_DB13 32 TouchP _BUSY 13 LCD_DB14 33 TouchP _OUT 14 LCD_DB15 34 TouchP _Penirq 15 LCD_CS 35 SD_OUT 16 N.C. 36 SD_SCK 17 LCD_RESET 37 SD_DIN 18 N.C. 38 SD_CS 19 LED_BL 39 N.C. 20 N.C. 40 N.C. Download Friendly customer service Fast and reliable shipping Offer wholesale prices on high volume orders Payment Methods of Payment: We accept payment via PayPal ONLY, other payment methods are NOT accepted. Payment MUST BE MADE within 5 business days after the completion of auction, we reserved the rights on order cancellation and re-selling the item on late payment. Non-paying bidders will be reported to eBay after 7 days in order to recover the money lost on listing fees. Policies Payments and Shipping Information Payments must be received within 7 days after the end of an auction. Upon receiving your payment, item(s) will be shipped within 24 working hours. Parcels will be shipped out within 1 business days after received the payment and delivery to the your registered address on PayPal which normally takes 7 -15 days. To avoid delays caused by delivery failure, please ensure your detailed address and full name registered on your PayPal account. If the parcel is required to deliver on an address which is not same to per registered on PayPal, please specify a note while you making the payment on PayPal. We will not responsible for extra shipment and delivery cost which is caused by a wrong or undeliverable address was supplied. Returns and Exchanges All returns/exchanges must be in brand new & resalable condition and in original packaging. Returns must be received by us within 14 days upon the delivery date of the order. It may takes up to 7 business days on processing the returned product(s). One year of warranty with free repair services will be provided for all Radio & Equipment products, which will be effective after 30 days from the date you received the product(s). Shipping & handling fees are non-refundable for all returned items. Feedbacks Our system will recognize a positive feedback and reply with a positive feedback automatically. Our goal is to satisfy all of our customers' needs. If you are unsatisfied in any ways with your order, please contact us before leaving a negative feedback. Custom Notice Products shipped from us will declare as gift and with no commercial value ( N.C.V.), shipping list and invoice will be excluded from the package, which can minimize the possibility for delays during clearance or any Import duties and Taxes issues raised by Customs. Please note you must borne for any additional charges, import duties or taxes in case it is still required from the Customs in your Country. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
