3.2" Tft Lcd Module Display + Touch Panel + Pcb Adapter Unique

US $16.26

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Recommendations For You 40% Off, $2.79 Now 50% Off, $2.65 Now 20% Off, $3.60 Now 20% Off, $3.60 Now 50% Off, $5.46 Now Visit my eBay Store:ChipWorld Product Name: NEW ICSC005A Steady 3.2" TFT LCD Module Display + Touch Panel + PCB adapter More Items In Our Store,Click Here! SKU: 4401 Parsts No. : Package: Brand: Quantity: 1 3.2 inch TFT Display Modules I,Feature 1)1).SSD1289 is an all in one TFT LCD Controller Driver that integrated the RAM, power circuits, gate driver and source driver into a single chip. 2)It can drive up to 262k color amorphous TFT panel with resolution of 240 RGB x 320. 3)It also integrated the controller function and consists of 172,800 bytes (240 x 320 x 18 / 8) Graphic Display Data RAM(GDDRAM) such that it interfaced with common MPU through 8-/9-/16-/18-bit 6800-series / 8080-series compatible parallel interface or serial peripheral interface and stored the data in the GDDRAM. Auxiliary 18-/16-/6-bit video interface (VSYNC, HSYNC, DOTCLK, DEN) are integrated into SSD1289 for animation image display. 4)SSD1289 embeds DC-DC Converter and Voltage generator to provide all necessary voltage required by the driver with minimum external components. A Common Voltage Generation Circuit is included to drive the TFT-display counter electrode. An Integrated Gamma Control Circuit is also included that can be adjusted by software commands to provide maximum flexibility and optimal display quality. 5)SSD1289 can be operated down to 1.4V and provide different power save modes. It is suitable for any portable battery driven applications requiring long operation period and compact size. 6)Mdules use parallel port to connect.it sustain 8 bit and 16 bit data pattern. It also support 3.3 Volt and 5 Volt power. Support backlight. The digital interface all is 3.3Volt to be drivered. The modules adopt XPT2046 touch chip,and it will be more precise . II,applied range It can be used to all kinds of MCU to display . Interface Simple , Control easy! III,relative parameters IV,Machine drawing unit:mm V,Function description product model :3.2 inch TFT display modules interface :3.3V parallel physical property:size :62.08mmx88.83mm Ambient operating temperature :celsius -20—80 degree Storage Temperature :celsius -40—85 degree humidity :relative humidity 5%—95% VII,matters need attention 1.Power switch: pad connected to power supply was connected to VCC 3.3V, the pad was not connected to VCC power supply 5V. 2.U2 (SST25VF016B) to 16 Mbit SPI Serial Flash, the default is not welded. 3.Backlight(LED_A) connect to 3.3 Volt? 4.This modules use 16 bit bus connected,so please use 16 bit bus(DB0-DB15 ALL CONNECTED) when be driver. For more quantity, please contact me.(My skype: ada-yu2013) The Standard shipping we provide is non-regiested mail without a tracking. We provide free shipping with tracking number when your order is over $50. If your oder is below $50 and you need tracking, please contact me. Maybe you request 2pcs 2.4GHz NRF24L01+ Antenna Wireless Transceiver Module For Microcontrol new 4pcs 433Mhz WL RF transmitter and receiver link kit for Arduino/ARM/MCU 20pcs 433Mhz WL RF transmitter and receiver link kit for Arduino/ARM/MCU good 5pcs new Breadboard 830 Point Solderless PCB Bread Board MB-102 MB102 Test DIY 9PCS NEW TEC1-12706 Thermoelectric Cooler Peltier 12V 60W 92Wmax good $ 3.8 + free shipping $ 6.0 + free shipping $ 28.0 + free shipping $18.0 +free shipping $ 28.0 + free shipping Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkFrog Analytics
