Description ERM2004FS-2 is 20 characters wide,4 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,fstn-lcd positive,black text on the white color,high contrast,wide operating temperature range,wide view angle,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set. It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment. Specification Gross Weight (kg) 0.0800 Manufacturer EastRising Series Number ERM2004-2 Part Number(Order Number) ERM2004FS-2 Connection Pin Header Display Format 20x4 Character Sunlight Readable Yes Touch Panel Optional No Outline Dimension 98.00(W)x60.0(H)x14.0(T)mm Visual Area 76.00x25.20mm Active Area 70.40(W)x20.80(H)mm Character Size 2.95x4.75mm Diagonal Size No Dot (Pixel) Size 0.55x0.55mm Dot Pitch 0.60x0.60mm IC Package COB IC or Equivalent AIP31066 , HD44780, KS0066 , SPLC780 , ST7066 Interface 6800 4-bit Parallel , 6800 8-bit Parallel Display Type FSTN-LCD Grey Response Time(Typ) No Contrast Ratio(Typ) No Colors No Viewing Direction 6:00 Viewing Angle Range No Appearance White on Blue Brightness(Typ) No Backlight Color White Color Backlight Current (Typ) 75mA Power Supply(Typ) 3.3V Supply Current for LCM(Max) 2000uA Operating Temperature -20°C~70°C Storage Temperature -30°C~80°C Datasheet - Character LCD Module,Controller IC Format Documents Name (Downloadable) Version Language Update Date Size 20x4 Character LCD Module Datasheet 1.0 English Jun-2013-25 352K Controller IC SPLC780C Datasheet 1.0 English Jul-2002-09 813K Learn - C51(8051) Demo Code,Interfacing Format Documents Name (Downloadable) Version Language Update Date Size 6800 4-bit/8-bit Parallel Interface Demo Code 1.0 English Jun-2013-25 5K ERM2004-2 Series Interfacing Document 1.0 English Jun-2013-25 185K About Us We're China-based global display manufacturer named EastRising Technology Co.,Ltd. that has a worldwide business in design, produce and sell various displays for small to large companies since 2003. Our web site is buydisplay.com. Link for video and image of our production line and equipment. RoHS reports for all material we used on display module. Long Term Continuity Supply Warranty We promise the long terms continuity supply and would never end.Some controller IC may stop the production,we'll try our efforts to find the completely compatible ones.If the equivalent is unavailable, we’ll make the new tooling and use the most similar IC as replacement.So you don't have to worry even your research time is very long. Shipping Policy All products will be checked carefully and packed in good condition before shipping.We e-mail all customers with tracking information immediately after the shipment for status tracking. Item will be shipped within 1 business day after the payment has been received. Customs fees and import duties for exports are buyer's responsibility. Warranty All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year from the date of receipt and all products are free of visual defects and missing parts for a period of 30 days from the date of receipt.If a product was damaged during shipping or the order is incorrect,you must notify us within 2 days of receipt. How to return a product First request an RMA number from our sales with the information:part number,reason for return,order number. Our sales will then either issue an RMA number, ask you for more information, or offer to help you resolve a technical problem so that the product does not need to be returned. Products must arrive here in the same condition as when you received them. You are responsible for return shipping and insurance.Please make sure your RMA number is on the shipping label and on any documents you include with the product. After we receive the product, we inspect it to determine the cause of any defect, then update by email with our findings. This process usually takes five business days.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	EastRising
Country/Region of Manufacture	China
Model	ERM2004FS-2
Country of Manufacture	China
MPN	ERM2004FS-2
