3.5inch Raspberry Pi Lcd Module 320x480 Tft Resistive Touch Display Spi For B/b+

US $26.98

???, ???, China
Jan 29th

Open on mobile:
QR code

3.5inch Raspberry Pi LCD Module 320x480 TFT Resistive Touch Display SPI for B/B+ Description: Designed for Raspberry Pi Model B/B+, an ideal alternative solution for HDMI monitor 320x480 resolution, better display Convenient Men-Machine interface for Raspberry Pi, combined with the portable power, DIY anywhere anytime Supports Raspbian system, enables your system to: Play videos (supports multi formats, MP4 and so on) Take photos by touching (up to 17 camera modes) Support software keyboard (system interaction without keyboard/mouse) Key Parameters: LCD Type:TFT LCD Interface:SPI Touch Screen Type:Resistive Touch Screen Controller:XPT2046 Colors:65536 Backlight:LED Resolution:320*480 (Pixel) Aspect Ratio:2:3 Power Consumption:TBD Backlight Current:TBD Operating Temp.(°C):TBD Interface: PIN NO. SYMBOL DESCRIPTION 1, 17 3.3V Power positive (3.3V power input) 2, 4 5V Power positive (5V power input) 3, 5, 7, 8, 10, 12, 13, 15, 16 NC NC 6, 9, 14, 20, 25 GND Ground 11 TP_IRQ Touch Panel interrupt, low level while the Touch Panel detects touching 18 LCD_RS Instruction/Data Register selection 19 LCD_SI / TP_SI SPI data input of LCD/Touch Panel 21 TP_SO SPI data output of Touch Panel 22 RST Reset 23 LCD_SCK / TP_SCK SPI clock of LCD/Touch Panel 24 LCD_CS LCD chip selection, low active 26 TP_CS Touch Panel chip selection, low active Package included: 1 x Rapsberry Pi 3.5 inch Touch Screen Dear buyers: Welcome to our store,Thanks! We try our best to provide you high quality and good service.Your satisfy is our aim. If you are satisfy with us,pleae leave five star positive feeback,and welcome to our store again,we will supply the good items and service all the time. If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve for you. Best Regards Shipping: We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Warranty and return: 12-months Warranty for defective items (excluding items damaged and/or misused after receipt). Refund or replacement request is available only the requests within 1 week after parcel received & returning the item as the same condition as received. Please contact us to request a return authorization. Your name, auction number, and reason for return should be included in the email. All items returned must contain all original packaging materials. Please repack the item carefully. Items returned will be tested and a new replacement will be shipped to the buyer immediately when found defective. In the event that a suitable replacement is not available then a refund will be issued. Shipping, handling and insurance fees are non refundable. Return shipping is to be paid by the Buyer. Contact us: We have much more products, if you need or have any question ,please contact us by leaving message or use Ali Trade manager .Welcome to wholesale. Thank you so much!
