3 Axis Tb6560 Cnc Stepper Motor Driver Controller Board High Quality Fks

US $47.85

Shanghai, China
Jan 31st

Open on mobile:
QR code

3 Axis TB6560 CNC Stepper Motor Driver Controller Board High Quality Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Features: This is brand new with high quality 100% Brand New Toshiba TB6560AHQ chip - High power, maximum 3.5A drive current chipset ! 1-1/16 microstep setting - Higher accuracy and smoother operation than standard 1, 1/2 step! Adjustable 0.5A-2.5A drive current settings for each axis - 25%,50%,75%,100% of full current can be set for different stepper motors Overload, over-current and over-temperature safety - Full protection for your computer and peripheral equipment ! On board current switching - Power output can be set according to specific user requirement ! Full closed-type optical isolation to protect the user's computer and equipment Relay spindle interface - Outputs Max. 36V 7.5A for spindle motors or coolant pump (only one device can be powered by this output!) 4 channel inputs interface- Can be used for XYZ limit and emergency stop ! Professional design - Two stage signal processing with super anti-jamming ! Bipolar constant current chopper drive with non-resonant region - Controls motors smoothly through range without creep effect ! Four control inputs (divided into pairs of knives) - Allows setting of limit and emergency stop ! Universal architecture - Supports most parallel software MACH3,KCAM4 etc! Specifications: Electrical properties (ambient temperature Tj = 25 °C pm): Input Power:12-36V DC power supply Stepper motor drive current:0.5A - 2.5A/phase Drive type:Double-pole constant flow PWM actuation output Compatible Stepper motors:2 or 4 phase, 4,6 or 8 lead stepper motors, 2.5A max. Dimensions: 18 * 14 * 4 cm (L*W*H) Please Note Please connect the power supply to the power switch of DC 12-36 V Voltage Selection: > 12-16V DC power supply for Nema 17 stepper motors > 16-24V DC power supply for Nema 23 stepper motors > 24-36V DC power supply for Nema 34 stepper motors The power output of 12V shall be applied to the radiator fan of 12V Driver output compatible with 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max. Suitable for unipolar or bipolar stepper motors. Voltage regulated spindle speed controlled by parallel interface as function of supply voltage. Package Includes 1 x 3 Axis TB6560 Stepper Motor Driver 1 x DB25 parallel cable 5 x Wire connectors 1 x CD software (English Manual & Mach 3) If the drive, datasheet, or instruction manual doesn't come with the parcel, just feel free to contact me. We will send them via email directly. Thanks for your cooperation. 1.Item will be shipped within 2 business days of cleared payment via Post Airmail. 2.Usually takes 15-25 business days to most Countries: US, Canada, UK, Australia and Europe. 3.Optionally, Express Shipments with tracking service via EMS with a quoted delivery time of 5 to 7 4.business days is also available . 1.We only accept PayPal. 2.Payment must be made within 7 calendar days of the auction end time. 3.We reserve the right to cancel your order if the payment is not made within 8 calendar days of checkout. inkfrog terapeak i000000 On Nov-28-14 at 20:27:32 PST, seller added the following information:
