3 Axis Usb 1500w Cnc 6040 Router Engraver Metal Milling Drilling Machine+remote

US $4200

Basel, Switzerland
Aug 3rd

Open on mobile:
QR code

Store category Sign Up Now ! You may also like 3 Axis USB 1500W CNC 6040 Router Engraver Metal Milling Drilling Machine+Remote Product Description Model 6040 Country/Region of Manufacture China X,Y,Z Working Area 600(Y)*390X*120(Z)mm Outside dimension 865*680*570mmL*W*H Table size 770Y*490Xmm Lathe structure 6061/6063 Aluminium alloy Max. Feeding height 100mm Stepping motor 57 two-phase 3A 150N.cm VOLTScurrentpower AC220 /50Hz5A,1.5KW VFD Spindle speed 24000 rpm Max working frequency 60Hz Principal axis collet ER11colletStandard configuration :6mm Nut Model ER11-A Cooling Water-cooling Lubrication way lubricated by high grease Repeat accuracy 0.05mm Spindle precision radial beat acuities 0.03mm Carving Instructions G code / TAB files / nc file / NCC files Carving speed 0-2500mm/min(different materials differ Brand Unbranded MPN Does Not Apply Custom Bundle Yes Control CNC Machine Type 3 Axis Router Machine SKU:3-1.5KW6040A-USB+3-1.5KW6040B-USB+TS007USB Description: Suitable for PCB, wood, Plexi glass, PVC, Crystal Acrylic, RESIN, Plastic, SEALS, MDF, COMPOSITE, Aluminum material, Copper, 1. This 3D 6040 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. 2. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. and soft metal .like aluminum, copper and silver to engrave them into 3D/2D works etc. 3. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin doublecolor plate,PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 4. The mini 3D router Frame is movable. The machine can connect with computer as other external device such as printer , scanner... 5. With the assist of the 3D ROUTER 6040T, your design idea will be real-time display. 3D engraving machine parameters: X, Y, Z Working Area: 600(Y)*390X*120(Z)mm Outside dimension: 865*680*570mmL*W*H Table size: 770Y*490Xmm Lathe structure: 6061/6063 Aluminium alloy Max. Feeding height: ≤100mm Drive unit: X axis---1605 Ball Screws Y axis---1605 Ball Screws Z axis---1204 Ball Screws Sliding unit: X axis---High intensity Chromeplate shaft Y axis---High intensity Chromeplate shaft Z axis---High intensity Chromeplate shaft Stepping motor: 57 two-phase 3A 150N.cm Spindle motor: (tips1. The spindle motor must connect with the VFD. 2. It cannot directly connect with the supply voltage (AC220V). 3. Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor.) Outside dimension: 65*158mm Material: 304 stainless steel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC220 /50Hz, 5A, 1.5KW VFD Spindle speed: 24000 rpm Max working frequency: 60Hz Principal axis collet: ER11colletStandard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency from 0-24000RPM Lubrication way: lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through USB connection with computer environment: Windows XP/Win7 Maximum speed: 0-4000mm/min Carving speed: 0-2500mm/min(different materials differ Control box parameters: Operating Voltage: AC220V Control unit: Toroidal transformer + PWM power supply module + TB6560 stepping motor drive

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	6040
Nut Model	ER11-A
Country/Region of Manufacture	China
Cooling	Water-cooling
X,Y,Z Working Area	600(Y)390X120(Z)mm
Lubrication way	lubricated by high grease
Outside dimension	865680570mmLWH
Repeat accuracy	0.05mm
Table size	770Y*490Xmm
Spindle precision	radial beat acuities 0.03mm
Lathe structure	6061/6063 Aluminium alloy
Carving Instructions	G code / TAB files / nc file / NCC files
Max. Feeding height	100mm
Carving speed	0-2500mm/min(different materials differ
Stepping motor	57 two-phase 3A 150N.cm
Brand	Unbranded
VOLTScurrentpower	AC220 /50Hz5A,1.5KW VFD
MPN	Does Not Apply
Spindle speed	24000 rpm
Custom Bundle	Yes
Max working frequency	60Hz
Control	CNC
Principal axis collet	ER11colletStandard configuration :6mm
Machine Type	3 Axis Router Machine
UPC	Does not apply
