3-channel 12-lead Lcd Display Ecg Machine Ecg301 Color Electrocardiograph

US $399.00

Trenton, New Jersey, United States
Jul 18th

Open on mobile:
QR code

3-Channel 12-LEAD LCD Display ECG machine ECG301 COLOR Electrocardiograph Features: 12-lead ECG simultaneous acquisition Three channels with interpretation 7-inch graphic LCD display, touch-screen and function key control Auto-regulation of baseline drift Automatically measuring and analyzing ECG parameters High-resolution thermal printer to print out ECG trace Specifications: Lead standard 12 leads lead acquisition synchronously 12 leads Input circuit Floating; Protection circuit against Defibrillator effect Input Impedance 50M Input circuit current 0.0.05A Record mode Automatic: 3CH4+1R, 3CH4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2; Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; Rhythm: Any lead selectable. Filter EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz / 60Hz CMRR >100dB Patient current leakage 10A Input Circuit Current 0.05µA Frequency Response 0.05Hz~150Hz (-3dB) Sensitivity 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV Anti-baseline Drift Automatic Time constant 3.2s Noise level 15Vp-p Paper speed 12.5 mm/s, 25 mm/s, 50 mm/s Recording mode Thermal printing system Paper specification 80mmx20m paper roll LCD display 7” graphic LCD Safety classification IEC60601-1 class I, type CF Power supply AC: 100~240V, 50/60Hz, 30VA~100VA DC: 14.8V/2200mAh, built-in lithium battery Fuse AC220V±10% 2*520mm,T2A/250V AC time lag AC110V±10% 2*520mm,T4A/250V AC time lag Package List: 1 x ECG Machine 1 x ECG Lead Wire 1 x Power Cable 1 x Thermal Printing Paper 1 x User Manual (CD) 4 x Limp Clip 6 x Chest Suction Ball Disclaimer: The ECG machine cannot substitute for the advice of a medical professional (for instance, a qualified doctor/physician, nurse, pharmacist/chemist, and so on). Please follow the instructions and we assume no responsibility or liability for any loss or damage suffered by any person as a result of misuse of this device.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ECG
ECG & EKG Machine Type	Electrocardiograph
Number of Channels	3
MPN	M600060
UPC	Does not apply
