3 Channel Color Organ - Improved Control - Light Organ Responds To Sound

US $24.95

Lawndale, California, United States
Jun 9th

Open on mobile:
QR code

3 Channel Color Organ - Lite Responds to Sound - Includes all parts & printed circuit board. PLEASE READ THIS, AND INSTRUCTION LINK BEFORE BUY !No Paper Instructions. Only a webpage link. There is a PDF file at the end of the instructions, which you can download and print ! In kit form, get yourself a circuit than controls incandescent lamps in response to ambient sound. This circuit connects directly to 120VAC, and can control upto 2amps (240W) of incandescent lamps per channel. An on-board microphone picks up ambient sound and modulates the lights. Each of the 3 channels responds to a certain portion of the audio spectrum (Bass, Mid-range, and Treble). This circuit is a major improvement over the old "color organ" circuit of the 70s. That circuit used probability (hit-n-miss) to roughly adjust brightness. This circuit uses true proportional pulse-width-modulation (PWM), to adjust brightness. It really takes advantage of the properties of the bidirectional thyristor, known as a TRIAC, to control brightness. Its not that crappy "color organ" circuit, of the 70's, that has just been blindly aped on the internet. No real original thought ! This circuit, syncs with the AC waveform, for true PWM. Mind the "Seven-Ps" people ! External connection are all made by way on 4 2-pin screw terminal blocks. They look like one 8-pin block, because they are interlocking, and come that way in the kit. It may be adapted to 220V use (Europe, & elsewhere), if the 0.47uf 250V capacitors (C14 & C15) are replaced with a single 0.47uf 400V film type capacitor. Note: Circuit must be used with 120VAC. It involves all risks with circuits directly connected to live HV AC. Load must be RESISTIVE. This means 120V incandescent bulbs, and possibly some types of 120V rated LEDs, or LED strings. Here's a link to all the instructions you need to build this kit, once you receive it: Color Organ Kit. Here's a video of the circuit in operation: Color Organ in action. Board measures 2.75in x 2.375in (70 x 60mm). It has 4, #4 (0.12", 3mm) mounting holes with 2.5" x 2" spacing. Note: The kit only includes the PCB and parts ! Not, the lamps, and sockets shown in one of the photos ! Its a KIT !!!! All kits are sorted and stored, in individual anti-static bags. They are shipped that way to the customer. Shipping Weight: 4 oz Items shipped to your eBay registered address (not Paypal's). Contact me using eBay's messaging system. I DO NOT read my email. Its used only as the Paypal payment link. Domestic shipments automatically have "Delivery Confirmation", which essentially is a tracking method. International shipments will only have their "Customs Declaration" number listed, unless the foreign buyer chooses "Registered Mail". With "Registered Mail", the package can be tracked. "Registered Mail", will incur and additional $12.00 US to the total cost. If you want this option please contact me and wait to be invoiced. If you just pay for it (without being invoiced), the item will be shipped without tracking. eBay only required that I (the seller) prove that I shipped it. A "Customs Declaration" will satisfy that requirement. Its your nickel. From NOW ON, if its lost and you DID NOT pay for registered mail, then THAT'S IT ! Please pay or contact me about payment within three days after the end of the auction. Paypal preferred. Domestic buyers contact for other payment methods. Paypal ONLY from foreign buyers. If you are sending your payment thru the mail, please email me that you are doing so. I have recently cancelled my mental telepathy services, so I can no longer read your minds.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Tortugascuba
Country/Region of Manufacture	United States
Model	CO3
Country of Manufacture	United States
MPN	CO3-Kit
