Description: Newest 3-channel ECG Holter System/Recorder Monitor Analyzer Software Version: NEW CardioScape Holter Model: CS-3CL Software Functions & Features: QRS Templates Apply Demix technology, ensures the accuracy of QRS templates, includes N (Normal), V (Ventricular Ectopy), S (SVE), U (Unknown), P (Pacemaker), A (Artifact). All the templates can be combined or separated as individual beats. beats can be superimposed. Weak signal can be identified such as P wave. Arrhythmia Analysis VE, SVE, aberrant beats, V-Tach, V-Pair, V-Bigeminy, Tri-geminy etc. HRT (VE Chaos) Analysis HRT is the most powerful ECG-related risk predictor for assessing the death risk following myocardial infarction. The predictive value is comparable with that of the LVEF. Pacemaker Analysis Unique pacemaker analysis is suitable for various models i.e. AAI, VVI, DDD, DDR pacemakers. HRV (Heart Rate Variability) Analysis Time domain and Spectral domain HRV analysis, superlower HRV analysis Heart Rate Variability is analyzed in both Time Domain and Frequency. The top of the HRV display shows the Poincare-Lorenz scatter plots. The lower left shows the Frequency power graph. The range boundaries for LF, LF and HF can be adjusted. The lower right shows the Time Domain histogram. Day and night times can be entered for Sleep Apnea and for A-Fib. Atrial Fibrillation and Atrial Flutter Analysis Atrial Fibrillation is very important for the cardiologist concern. Holter ECG is an excellent test to detect transient A-Fib. TWA (T-wave alterans) Analysis Unknown for the past 40 years, T-Wave Alternans (TWA) in excess of 20 micro-volts have been in Holter recordings but have been undetected. TWA is a strong predictor of V-Tach and other serious cardiac abnormalities. It takes less than 10-seconds to do a complete 24-hour TWA analysis. You can check for TWA anywhere in teh 24-hour ECG file. Not only can you detect TWA in the ECG file, this software lets you view the ECG showing the actual TWA, so that you can verify and validate the presence of real TWA. The TWA algorithm detects two modes of TWA. Mode 1 is the beat-to-beat change in T-Wave amplitudes exceeding 20 micro-volts, as shown in the adjacent picture. Mode 2 is the gradual up and down changes of T-wave amplitudes over a series of several beats. Features: 12-lead Color LCD Holter recorder Compact size, light weight Fully programmable, high Fidelity Lower power consumption Fast data transfer Pacemaker detection Specification: Channel: 3 digital recording channels for 12-lead Sample rate: 1000Hz Resolution: 12 bit sampling Frequency response: 0.05-60Hz Recording time: 24 hours, full disclosure, no data compression, 12-lead ECG Storage: 2G built-in flash memory LCD display: ECG waveform and lead number Dimension: 80mmx45mmx18mm Weight: 75 grams (battery not included) Lead: 10 wire patient cable (I, II, III, aVR, aVL, aVF, V1~V6) Power: 2 AA size battery Packing list: 1. Holter Recorder: 1 set (Newest Version,so no dangle key) 2. Software: 1 pc (Newest Version) 3. 5-lead Holter lead wire: 1 set 4. Operation Manual: 1 set Safe product:The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. Do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, by bidding, you verify your status as an authorized purchaser of this item. If you have any questions refer to the FDA website: http://www.fda.gov The Fingertip Pulse Oximeter is certified with the US FDA 510K No. K070371, the CE & TUV of Eureope and it is on the Australian Register of Therapeutic Goods (ARTG) with the code 136606. Payment information: PayPal only. Please pay the money within 5 days after the auction ended. Shipping method: All items will be shipped by ePacket or Airmail post within 1 business days. It takes approximately 7-14 business days to USA, 18-35 days to other countries. If you don't want to wait for so long time, you need to pay the Express fee. We will send you a email of the detailed tracking information after the shipment of the goods. We are not Responsible for your Customs duty. We don't add taxes, VAT or other hidden charges. You pay us what you see on the invoice, i.e. goods subtotal + shipping cost (not include duties). Please find out as much as you can about your import taxes in your own country before bidding the item. You need to pay for the import duties in case that occurred for certain goods. Return Policy : If you receive a defective item which you want to return, please contact us within 2 days from the day you receive the item. All return items must be returned with its original packaging and accessories. If we confirm the damage happened during the shipment, we will bear the shipping cost for return.We will refund the money to you when we get the return items. Or replace item for you free of charge. Feedback: Contact us first before leaving a negative, we will find a solution to meet your requirement and enhance the satisfaction. About us Our Duty Time China Time USA(pacific time) Start End Start End Monday AM 9:00 PM 18:00 Sunday PM 17:00 Monday AM 2:OO Tuesday AM 9:00 PM 18:00 Monday PM 17:00 Tuesday AM 2:OO Wednesday AM 9:00 PM 18:00 Tuesday PM 17:00 Wednesday AM 2:OO Thursday AM 9:00 PM 18:00 Wednesday PM 17:00 Thursday AM 2:OO Friday AM 9:00 PM 18:00 Thursday PM 17:00 Friday AM 2:OO Saturday Out of Duty Friday Saturday Sunday Out of Duty Saturday Sunday Quality First, Service Excellent, Global Trust! We are the manufacturer and distributor of medical equipments for more than 10 years. If you are interested in the distribution work, please feel free to contact us. We will reply to you within 24 hours. Please kindly wait for us. Contact us During the duty time ,we can give you a quick respond. If we are out of work ,please kindly be patient and considerable to give us a little more time ,not just leave the neutral or negative feedback without communication ,thank you for your cooperation ! For more information, please feel free to contact us
