3 Phase 380v 0.75kw 2.1a Inverter V8t00075t Wantrend New

US $266.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

3 Phase 380V 0.75KW 2.1A Inverter V8T00075T Wantrend New Note: G (General) type is for general application; P (pump) type is specially for fan and water pump application; Model explanation: Features: *Covering multiple voltage levels: single-phase 220V, 3 phase 380V, 3 phase 480V, 3 phase 690V etc. *Hardware with current limiting by wave function to reduce the probability of overcurrent of the inverter. *Control in one for asynchronous machine and permanent magnet synchronous machine. *Support multiple bus, support RS485, ProfiBus, CANLink, CANOpen fieldbus interface. *Factory accuracy of AO/AI analog increased(only for control panel, not extended card IO). *Can increase motor overheating protection by expansion card(PT100, PT1000), isolation +/- 10V input. *Increase user programmable function (PLC), programming method can be compatible with H1u series PLC. (during developing) *With powerful functions: -Motor switching, VF separation, internal condition monitoring; -Background monitoring software: upload and download function code, oscilloscope etc.; -Strengthen the function of virtual IO, digital and analog data captured by remote devices such as data sampling unit and intermediate variables of control system can be acted as IO or variable of this unit. *Performance improvement: -Optimize the VF oscillation suppression; -Improved the VF low frequency output; -Wider the scope of SVC debugging (1:200), and can realize SVC torque control; -The output torque ability of FVC weak magnetic area be stronger; Basic wiring diagram: Specifications Item Specifications Standard functions Maximum frequency Vector control: 0–300 Hz V/F control: 0–320 Hz Carrier frequency 0.5–16 kHz The carrier frequency is automatically adjusted based on the load features. Input frequency resolution Digital setting: 0.01 Hz Analog setting: maximum frequency x 0.025% Control mode Sensorless flux vector control (SFVC) Closed-loop vector control (CLVC) Voltage/Frequency (V/F) control Startup torque G type: 0.5 Hz/150% (SFVC); 0 Hz/180% (CLVC) P type: 0.5 Hz/100% Speed range 1:100 (SFVC) 1:1000 (CLVC) Speed stability accuracy +/- 0.5% (SFVC) +/- 0.02% (CLVC) Torque control accuracy +/- 5% (CLVC) Standard functions Overload capacity G type: 60s for 150% of the rated current, 3s for 180% of the rated current; P type: 60s for 120% of the rated current, 3s for 150% of the rated current; Torque boost Fixed boost Customized boost 0.1%-30.0% V/F curve Straight-line V/F curve Multi-point V/F curve N-power V/F curve (1.2-power, 1.4-power, 1.6-power, 1.8-power, square) V/F separation Two types: complete separation; half separation Ramp mode Straight-line ramp S-curve ramp Four groups of acceleration/deceleration time with the range of 0.0–6500.0s DC braking DC braking frequency: 0.00 Hz to maximum frequency Braking time: 0.0-36.0s Braking action current value: 0.0%-100.0% JOG control JOG frequency range: 0.00–50.00 Hz JOG acceleration/deceleration time: 0.0–6500.0s Onboard multiple preset speeds It implements up to 16 speeds via the simple PLC function or combination of DI terminal states. Onboard PID It realizes process-controlled closed loop control system easily. Auto voltage regulation (AVR) It can keep constant output voltage automatically when the mains voltage changes. Overvoltage/ Overcurrent stall control The current and voltage are limited automatically during the running process so as to avoid frequent tripping due to overvoltage/overcurrent. Torque limit and control It can limit the torque automatically and prevent frequent over current tripping during the running process. Torque control can be implemented in the CLVC mode. Individualized functions High performance Control of asynchronous motor and synchronous motor are implemented through the high-performance current vector control technology. Power dip ride through The load feedback energy compensates the voltage reduction so that the AC drive can continue to run for a short time. Rapid current limit It helps to avoid frequent overcurrent faults of the AC drive. Virtual I/Os Five groups of virtual DI/Dos can realize simple logic control. Timing control Time range: 0.0-6500.0 minutes Individualized functions Multi-motor switchover Four motors can be switched over via four groups of motor parameters. Multiple communication protocols It supports communication via Modbus-RTU, PROFIBUS-DP, CANlink and CANopen. Motor overheat protection The optional I/O extension card enables AI3 to receive the motor temperature sensor input (PT100, PT1000) so as to realize motor overheat protection. Multiple encoder types It supports various encoders such as differential encoder, open-collector encoder, resolver, UVW encoder, and SIN/ COS encoder. RUN Running command source Operation panel Control terminals Serial communication port You can perform switchover between these sources in various ways. Frequency source There are a total of 10 frequency sources, such as digital setting, analog voltage setting, analog current setting, pulse setting and serial communication port setting. You can perform switchover between these sources in various ways. Auxiliary frequency source There are ten auxiliary frequency sources. It can implement fine tuning of auxiliary frequency and frequency synthesis. Input terminal Standard: 5 digital input (DI) terminals, one of which supports up to 100 kHz high-speed pulse input 2 analog input (AI) terminals, one of which only supports 0–10 V voltage input and the other supports 0–10 V voltage input or 4–20 mA current input Expanding capacity: 5 DI terminals 1 AI terminal that supports -10–10 V voltage input and also supports PT100\PT1000 RUN Output terminal Standard 1 high-speed pulse output terminal (open-collector) that supports 0–100 kHz square wave signal output 1 digital output (DO) terminal 1 relay output terminal 1 analog output (AO) terminal that supports 0–20 mA current output or 0–10 V voltage output Expanding capacity: 1 DO terminal 1 relay output terminal 1 AO terminal that supports 0–20 mA current output or 0–10 V voltage output Display and operation on the operation panel LED display It displays the parameters. Key locking and function selection It can lock the keys partially or completely and define the function range of some keys so as to prevent mis-function. Protection mode Motor short-circuit detection at power-on, input/output phase loss protection, overcurrent protection, overvoltage protection, undervoltage protection, overheat protection and overload protection Environment Installation location Indoor, free from direct sunlight, dust, corrosive gas, combustible gas, oil smoke, vapour, drip or salt. Altitude Lower than 1000 m Ambient temperature -10°C to +40°C (de-rated if the ambient temperature is between 40°C and 50°C) Humidity Less than 95%RH, without condensing Vibration Less than 5.9 m/s2 (0.6 g) Storage temperature -20°C to +60°C IP level IP20 Pollution degree PD2 Power distribution system TN , TT Applications: *Chemical fiber and textile: carding machine, sizing machine, central air conditioning, air blower, spinning machine, spinning machine, weaving machine, pumps, etc. *Automobile manufacturing: paint mixing, central air conditioning, conveyor belt, etc. *Machine tool manufacturing: grinding machine, machining center, lathe, planer, milling machine, shaving machine, etc. *Electronic manufacturing: air compressor, injection molding machine, central air conditioning, fan and pump, conveyor belt, etc. *Paper making industry: paper machine, paper making machinery, blower fan and pump, grinder, mixer, etc. *Food: conveyor belt, mixer, noodle machine, snack making machine, etc. *Gas, water: air blower, pump, compressor, etc. *Cement: rotary kiln, hoisting machinery, air blower, pump, main drive motor, conveyor, vibrating feeder and standing Kiln fan, etc. *Mining: mud pump, conveyor, hoist, cutting machine, digging cutting machine, crane, blower, pump, compression Machine, etc. *Transportation: electric cars, electric locomotive, ship propulsion, loading and unloading machinery, air compressor, electric cable car, etc. *Handling: automatic warehouse, truck, powder delivery device, output conveyor belt, etc. *Construction: elevator, conveyor belt, air conditioning equipment, air blower, pumps, etc. *Plastic: rubber cutting machine, injection molding machine, extruder, plastic film production line, etc. *Life, services: air compressor, sewing machines, electric fans, industrial and home use washing machine, etc. *Logistics: three-dimensional garage, automatic warehouse, conveyor belt, etc. *Electric power: boiler feed water pump, centrifugal mixer with blower,, conveyor belt, pumping stations, flywheel, etc. *Hotels, building: central air-conditioning system, elevators, etc. *Agriculture: tea machine, water pump, ventilation, etc. *Metallurgical industry: rolling mill, roller, the blast furnace blower, pump, hoisting machinery, blast furnace feeding, steel mills, polishing, etc. *Steel rolling: line drawing machine, winding machine, blower, pump, hoisting machinery, fixed-length cutting, automatic feeding; *Steel: rolling mill, roller way, fan, pump, crane and ladle car, converter tilting, etc. *Chemical industry: conveyor belt, mixer, extruding machine, film centrifugal separator, compressor, blower, sprayer, Pumps, etc. *Oil: oil transfer pump, electric submersible pump, injection pumps, pumping unit, etc. We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM Shipment: Once payment received. Item will be shipped out within 1-3 working days by DHL, Fedex, UPS, EMS ASAP. Usually it takes 3-7 working days to most of the country. You will be notified the traking number once shipped out. Kindly please note the Tax fee and Customs clearance fee are not included in the item’s listing price. Kindly please feel free to contact us before shipping if there’s any thing we can do for you. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: We accept return or refund within 14 days for the quality reason, not man-made reason. Kindly please contact us before returning the package. Payment will be refunded to you within 24hrs once the package received by us. You understanding appreciate. Kindly note: Pls check and confirm the part NO. and your application before place order, any further assistance please feel free to let us know.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Wantrend
MPN	V8T00075T
Model	V8T00075T
